- Page 1 FREEDIVING COMPUTER...
-
Page 2: Table Of Contents
COUNTDOWN ............17 WATCH: ................5 ALARM ................17 DIVE COMPUTER .............5 PC-MAC SYNCHRONIZATION .....18 SWITCHING ON THE DRIVER.......6 DRIVER - TECHNICAL CHARACTERISTICS .19 SWITCHING OFF THE DRIVER.....6 1. APPEARANCE ............19 SEQUENCE OF FUNCTIONS ......7 2. TIME ................19 OPERATING MODES ...........7 3. DIVE MODE .............19 SET T1 MODE (WATCH, CALENDAR, 4. -
Page 3: Driver Manual
DRIVER DRIVER MANUAL Congratulations on your purchase of a SEAC freediving computer. The SEAC Driver is a technologically advanced instrument, designed and manufactured to provide all the information a freediver or spearfisherman needs. Check www.seacsub.com for any updates to this manual. - Page 4 • WARNING! It is strictly forbidden to freedive in the 12 hours after diving with scuba equipment! Violating this rule could considerably increase the risk of decompression sickness. • WARNING! Do not share one computer between two divers during the dive. Every diver must have their own instrument to provide information and save only that diver's data.
-
Page 5: Technical Characteristics
DRIVER TECHNICAL CHARACTERISTICS WATCH: • 12/24 clock with minutes and seconds • Second time setting • Option to switch between primary and secondary time • Calendar • Stopwatch • Countdown • Alarm DIVE COMPUTER • Function indicating the minimum suggested recovery time between one dive and the next: MSST (Minimum Suggested Surface Time) •... -
Page 6: Switching On The Driver
SWITCHING ON THE DRIVER If the Driver display is off, press the “M” button for at least five seconds to turn it on. SWITCHING OFF THE DRIVER If the Driver will not be used for an extended period, you can turn the instrument off to save energy in the battery. -
Page 7: Sequence Of Functions
DRIVER SEQUENCE OF FUNCTIONS • Watch mode T1 and T2, calendar, temperature • DIVE: dive and surface time data • LOG: Logbook • CHR: Stopwatch • CDT: Countdown • ALM: Alarm • Backlighting: press the “E” button on the upper left to turn on display backlighting for five seconds. -
Page 8: Second Time Zone (T2)
• The hours digits flash: increase the value with the “U” button or decrease with the “D” . Briefly press the “M” button to confirm. • The 12 or 24 hour indication flashes. Use the “U” and “D” buttons to set the desired option and briefly press “M”... -
Page 9: Set T2 Mode (Second Time Zone)
DRIVER SET T2 MODE (SECOND TIME ZONE) T2 TIME SETTING mode Set T2 Hour Set T2 Minute Default time: 12:00:00 • To enter SET “T2”, set T2 as the primary display, and then press and hold the “M” button from the T2 screen. - Page 10 • On the “DEPTH AL” screen, the maximum depth alarm setting flashes: increase the value with the “U” button or decrease with the “D” . Briefly press the “M” button to confirm. • The ON/OFF setting for the alarm set for exceeding maximum depth flashes: Use the U/D buttons to select “ON”...
-
Page 11: T1 (Watch) And T2 (Second Time Zone) Modes
DRIVER T1 (WATCH) AND T2 (SECOND TIME ZONE) MODES TIME mode TIME (T1) mode T1<->T2 Transition T2 TIME mode month-day DOW screen TEM screen current time day of week / temp (hh:mm) second • In T1 mode (current time), the month-day and day of the week are shown at the top, with the current time in the middle and the seconds at the bottom. -
Page 12: Dive Mode
1. Manually, by pressing the “U” button for 2 seconds from the DIVE screen. 2. Automatically, by descending to a depth of at least 1.5 meters. Whatever function the Driver is in, it will automatically switch to the Dive function. -
Page 13: Alarms During The Dive
• WARNING! If you fail to respect the MSST and dive early, the Driver will signal a violation with an auditory alarm as soon as you descend past 1.5 meters. (At the user's full responsibility, this can be disabled. See SET DIVE... - Page 14 When this happens the Driver can no longer save data for subsequent dives, although it is still able to provide information on dives as they happen. To allow the Driver to resume saving data, you will need to empty the memory by permanently deleting the data (see instructions under “Deleting logbook archive”);...
-
Page 15: Logbook Mode
DRIVER LOGBOOK MODE The Driver logbook is organized into sessions, meaning a group of dives that occur close together, up to 199 dives per session. Maximum permitted surface interval between one dive and the next before the session is considered complete is 59’59”, unless you terminate it manually. -
Page 16: Stopwatch
NOTE The Driver can store data for up to 500 dives. Naturally, this depends on the save frequency you have set (1 or 2 seconds) and the length of your dives. It can save up to 99 sessions, and each session can contain up to 199 dives. -
Page 17: Countdown
DRIVER COUNTDOWN • The minutes and hours (max 23 hours, 59 minutes) will be shown in the middle of the display, and the seconds at the bottom. • Start, stop, and restart the countdown with the U button. The D button resets the counter. -
Page 18: Pc-Mac Synchronization
Driver. Before performing this operation, make sure that the four metal contacts on both the Driver and the plug are very clean to ensure data transmission. -
Page 19: Driver - Technical Characteristics
DRIVER DRIVER - TECHNICAL CHARACTERISTICS 1. APPEARANCE Display: • FSTN LCD • 3 Row Display 4 Buttons Water resistance: 100 Meters 2. TIME Show hour, minute, second, date and day of week Calendar Range : 2000 ~ 2099 12/24 hour format selectable... -
Page 20: Dive Logbook
• Minimum Suggested Surface Time alert with on/off 4. DIVE LOGBOOK Memory: • Max up to 99 sessions • Max up to 500 dive records • Max up to ~21,000 logging items Log rate: 1/2 seconds selectable (2 seconds default) Delete all function Session information includes: •... -
Page 21: Chronograph
DRIVER 6. CHRONOGRAPH Max 23H59M59S 7. COUNT DOWN TIMER Max 23:59:59 1 second resolution Beep once per minute during last 10 minutes. Beep once every 10 seconds during last minute. Beep once per second for final five seconds. Beep continuously for 30 seconds when timer reaches zero. -
Page 22: Replacing The Battery
Make sure that the O-Ring is not damaged, and once inserted make sure it isn't twisted at any point. f) Position the cover on the Driver case, and press it evenly downward. Make sure that in the area around the screws, the cover is flush with the case. -
Page 23: Driver Serial Number
DRIVER DRIVER SERIAL NUMBER The Driver serial number is engraved into the back of the case, on the side opposite the PC-link contacts. EC CERTIFICATION The Driver is compliant with EC Directives. CARE AND MAINTENANCE • Keep your computer clean and dry. Do not expose the computer to chemical agents, including alcohol. -
Page 24: Disposing Of The Driver
The mineral glass is subject to possible scratches resulting from improper use. • WARNING! Do not use jets of compressed air to dry or clean the Driver. This could damage the pressure sensor. • WARNING! Do NOT use solvents to clean the product. Use only running water. - Page 25 6. This warranty may also be exercised by shipping the product believed to be defective to SEAC. The authorized intermediary for this operation must be the SEAC dealer where the product was purchased. If this is not practically possible, solely upon authorization from SEAC, customers may by authorized to send the defective product to any other SEAC dealer or directly to SEAC itself.
- Page 26 SEAC will not carry out any investigations on the product, and will advise the sender/authorized dealer. If the sender still wishes an inspection to be performed, a request to that effect must expressly state that he/she is willing to bear all the costs relevant to said inspection (labor, spare parts if any, and shipping charges).
- Page 27 DRIVER...
- Page 28 SEACSUB S.p.a. Via D. Norero, 29 San Colombano Certenoli (GE) 16040 Italy Phone +39 0185 356301 Fax +39 0185 356300 seacsub@seacsub.com www.seacsub.com SEAC USA Corp. Phone +1 786 580 3695 seac.usa@seacusa.com www.seacusa.com 10/18 • Artbook 14964/18...
Need help?
Do you have a question about the DRIVER and is the answer not in the manual?
Questions and answers
When I push in any button on the watch it turns off I’ve replaced the battery still same problem any idea what the problem is? I have a video of what happens I can send.
The Seac DRIVER watch turning off when any button is pressed, even after replacing the battery, could be caused by improper battery installation or poor battery contact. Users have reported similar issues where the watch reset unexpectedly, often when pressing buttons or after a light shake. Ensuring that the battery is correctly inserted and making proper contact may resolve the issue. Additionally, this type of problem is common in many digital watches, indicating it could be a design or contact issue rather than a battery defect.
This answer is automatically generated
@Mr. Anderson @Mr. Anderson the battery is as secure as it can be it slots right into the clips and is held in tight even a heavy bump wouldn’t be able to dislodge it.
