FITTING AND USING THE BLADE ASSEMBLY

• 2-BLADE ASSEMBLY :
We recommend you use the 2-blade assembly for processing small quantities of up to
half the maximum limit indicated (see page 22), with the exception of liquid or blended
preparations.
Correct positioning of
2-blade assembly (top view)
180°
Position 1
POSITION 1 : With spacer between lower blade and blade shaft.
• For coarse chopping.
FITTING : • Fit the blades and spacers so that they are the right distance apart,
according to the :
- type
- weight and
- volume of the foodstuffs to be processed.
Screw nut
Locking spacer
• 3-BLADE ASSEMBLY :
We recommend you use the 3-blade assembly for processing large quantities of more
than half the maximum limit indicated, with the exception of liquid or blended prepa-
rations for which we strongly recommend you use the 2-blade assembly.
To obtain the best possible results with these types of preparation, we recommend
you use the lower speed (1,500 rpm) only.
Position 2
POSITION 2 :
DISMANTLING :
Wide spacer
Narrow spacer
Correct positioning of
3-blade assembly (top view)
120°
120°
Position 1
No spacer between lower blade and blade shaft.
• For fine chopping and emulsions.
• For grinding and kneading.
• Unscrew the screw nut
• Remove the spacers.
Blade
Blade shaft
Position 2
