7-2

Starting and Stopping Spindle Rotation

The procedures for starting and stopping spindle rotation in manual operation are described here.
<Starting spindle rotation>
DOOR INTERLOCK
NORMAL
MRDY
TRCL
CHCL
PANEL
ON
OFF
1
MEM MDI
H JOG
RELEASE
ERR
X
Z
PANEL
/EDIT
2
TAPE EDIT
RPD ZRN
1) Place the DOOR INTERLOCK key-switch in the
NORMAL position.
2) Check the chucking pressure with a pressure gage.
If it is incorrect, adjust the pressure.
Page C-7 (2-1)
3) Clamp a workpiece in the chuck.
Page B-32 (7-3)
4) Make sure that the status indicator [CHCL] is lit.
If it is not lit, check the workpiece chucking status
NOTE
and the setting for the chucking direction.
5) Place the PANEL key-switch in one of the positions
indicated below.
(ON)
6) Press the HEAD CHANGE switch
(head 2) to select the spindle to be rotated. (S
2
type)
7) Select any of the following modes with the mode
selection switch.
(H)
(RPD)
MANUAL OPERATION
(PANEL/EDIT)
(head 1) or
1
(JOG)
(ZRN)
B-29
