A-48 OPERATION PANELS
5-16

Machine Light Switch [LIGHT]

LIGHT
On
Off
5-17

Chip Conveyor Switches (Chip Conveyor Specification)

FOR
Switch
FOR
STOP
BACK
LIGHT
Pressing this switch turns on the machine light. At the same time, the indicator
in the switch is lit.
Pressing this switch while the machine light is lit turns off the machine light. The
indicator in the switch also goes off.
For the procedure for changing the lamp, refer to the MAINTENANCE INFORMATION.
STOP BACK
When this switch is pressed, the indicator in the switch is lit and the chip
conveyor moves forward to discharge chips.
This switch is valid until the
When this switch is pressed, the chip conveyor stops.
When this switch is pressed, the indicator in the switch is lit and the chip
conveyor moves backward.
The chip conveyor moves backward only while this switch is held down.
If the chip conveyor is blocked by chips, press this switch to remove the
chips from the chip conveyor.
The LIGHT switch is used to turn the machine light on/off.
Function
The chip conveyor switches are used to manually operate
the chip conveyor.
Close the front door before operating the chip
NOTE
conveyor.
Function
(STOP) switch is pressed.
