- Page 1 CS632-C246/Q370 ATX Industrial Motherboard User’s Manual Preliminary Version A53100916...
-
Page 2: Copyright
Copyright FCC and DOC Statement on Class B This publication contains information that is protected by copyright. No part of it may be re- This equipment has been tested and found to comply with the limits for a Class B digital produced in any form or by any means or used to make any transformation/adaptation without device, pursuant to Part 15 of the FCC rules. -
Page 3: Table Of Contents
Table of Contents USB Ports ....................23 Audio ......................24 I/O Connectors ................... 25 SATA (Serial ATA) Connectors ..............25 Digital I/O Connector .................. 25 Copyright ......................2 Cooling Fan Connectors................26 Power Connectors ..................26 Trademarks ......................2 Chassis Intrusion Connector ................ 27 Front Panel Connector ................ -
Page 4: Warranty
Warranty Static Electricity Precautions 1. Warranty does not cover damages or failures that arised from misuse of the product, It is quite easy to inadvertently damage your PC, system board, components or devices even inability to use the product, unauthorized replacement or alteration of components and before installing them in your system unit. -
Page 5: About The Package
The package contains the following items. If any of these items are missing or damaged, please contact your dealer or sales representative for assistance. • One CS632-C246/Q370 motherboard • One COM port cable (Length: 400mm, 2 x COM ports) •... -
Page 6: Chapter 1 - Introduction
Chapter 1 Chapter 1 - Introduction Specifications SYSTEM Processor CS632-C246: INTERNAL I/O Serial 5 x RS-232 (2.54mm pitch) 8th Generation Intel Xeon Core™/Pentium /Celeron LGA 1151 Socket Processors with TDP up ® ®/ ® ® 2 x USB 3.1 Gen2 (opt., MOQ required) to 95W 5 x USB 2.0 (2.54mm pitch) (4 x Pin Header, 1 x USB 2.0 vertical Type A) -
Page 7: Features
Chapter 1 • Wake-On-LAN Features This feature allows the network to remotely wake up a Soft Power Down (Soft-Off) PC. It • Watchdog Timer is supported via the onboard LAN port or via a PCI LAN card that uses the PCI PME (Power Management Event) signal. - Page 8 Chapter 1 • Power Failure Recovery When power returns after an AC power failure, you may choose to either power-on the system manually or let the system power-on automatically. • USB The system board supports the new USB 3.1 Gen2. It is capable of running at a maximum transmission speed of up to 10 Gbit/s (1.2 GB/s) and is faster than USB 3.1 Gen1 (5 Gbit/s, or 625 MB/s), USB 2.0 (480 Mbit/s, or 60 MB/s) and USB 1.1 (12Mb/s).
-
Page 9: Chapter 2 - Hardware Installation
9-10 11-12 Digital I/O Power Select (JP17) USB 2.0 Digital I/O 0~3 Output State (JP18) Digital I/O 4~7 Output State (JP19) • Dual Channel DDR4 2400/2666MHz (ECC/non ECC) (CS632-C246) Dual Channel DDR4 2400/2666MHz (CS632-Q370) Chapter 2 Hardware Installation www.dfi .com... -
Page 10: Installing The Dimm Module
Chapter 2 The system board supports the following memory interface. Installing the DIMM Module Single Channel (SC) Note: The system board used in the following illustrations may not resemble the actual Data will be accessed in chunks of 64 bits from the memory channels. board. -
Page 11: Cpu
Chapter 2 6. Grasping the module by its edges, position the module above the socket with the “notch” in the module aligned with the “key” on the socket. The keying mechanism ensures the module can be plugged into the socket in only one way. The system board is equipped with a surface mount LGA 1151 socket. -
Page 12: Installing The Cpu
Chapter 2 Load lever 5. Lift the load lever to lift Installing the CPU the load plate. 1. Make sure the PC and all other peripheral devices connected to it has been powered down. Lift the load lever up to the angle shown on the 2. - Page 13 Chapter 2 7. Insert the CPU into the 8. Close the load plate then Load lever socket. The gold triangular push the load lever down. mark on the CPU must align with the corner of While closing the load the CPU socket shown on plate, make sure the front Retention knob edge of the load plate...
-
Page 14: Installing The Fan And Heat Sink
Chapter 2 Installing the Fan and Heat Sink 4. Rotate each push-pin ac- cording to the direction of the arrow shown on top of The CPU must be kept cool by using a CPU fan with heat sink. Without sufficient air circula- the pin. -
Page 15: Jumper Settings
Chapter 2 Jumper Settings 2 4 6 2 4 6 2 4 6 COM 1 RS232/422/485 Select 1 3 5 1 3 5 1 3 5 1-3, 4-6 On: 3-5, 4-6 On: 3-5, 2-4 On: RS232 (default) RS422 Full Duplex RS485 COM 1 JP1/JP2... -
Page 16: Com 1 Rs232/Power Select
Chapter 2 COM 1 RS232/Power Select 2 4 6 2 4 6 COM 1 1 3 5 1 3 5 3-5 (+5V), 4-6 (+12V) On: 1-3 (RI-), 2-4 (DCD-) On: RS232 with power RS232 (default) COM 1 1 2 3 4 5 6 7 8 9 RS232 RS232 with power... -
Page 17: Digital I/O Power Select
Chapter 2 Digital I/O Power Select Digital I/O Output State 1-2 On: +5VDU (default) JP17 2-3 On: DIO 0~3 DIO 4~7 (JP18) (JP19) JP17 is used to select the power of DIO (Digital I/O) signal: +5VDU (default) or +5V. 1-2 On: 2-3 On: Digital I/O Power (default) -
Page 18: Mini Pcie/Msata Signal Select
Chapter 2 Mini PCIe/mSATA Signal Select Mini PCIe/mSATA Power Select 1-2 On: 1-2 On: 3V3DU (default) Mini PCIe (default) JP22 JP21 2-3 On: 2-3 On: mSATA JP21 is designed to select the Mini PCIe (default) or mSATA signal. JP22 is designed to select the Mini PCIe/mSATA power: 3V3DU (default) or 3V3. Chapter 2 Hardware Installation www.dfi... -
Page 19: Clear Cmos
Chapter 2 Clear CMOS 1-2 On: Normal (default) 2-3 On: Clear CMOS If you encounter the followings, a) CMOS data becomes corrupted. b) You forgot the supervisor or user password. you can reconfigure the system with the default values stored in the ROM BIOS. To load the default values stored in the ROM BIOS, please follow the steps below. -
Page 20: Rear Panel I/O Ports
Chapter 2 Rear Panel I/O Ports PS/2 Keyboard/Mouse Port PS/2 Keyboard/Mouse COM 1 LAN 1 LAN 2 DP++ 1 PS/2 KB/MS Line-out USB 2.0 Mic-in DP++ 2 USB 3.1 Gen1 The rear panel I/O ports consist of the following: • 1 PS/2 Keyboard/Mouse port •... -
Page 21: Com (Serial) Ports
Chapter 2 COM (Serial) Ports Connecting External Serial Ports Your COM port may come mounted on a card-edge bracket. Install the card-edge bracket to an available slot at the rear of the system chassis then insert the serial port cable to the COM COM 1 connector. -
Page 22: Graphics Interfaces
Chapter 2 Graphics Interfaces RJ45 LAN Ports The display ports consist of the following: • 1 VGA port • 2 DP++ ports LAN 1 LAN 2 LAN 1 DP++ 1 LAN 2 DP++ 2 Features • 1 Intel ® I211AT PCIe •... -
Page 23: Usb Ports
Chapter 2 USB Ports Driver Installation You may need to install the proper drivers in your system operation to use the USB device. Refer to your operating system’s manual or documentation for more information. USB 8 USB 7 Wake-On-USB Keyboard/Mouse USB 2.0 The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state. -
Page 24: Audio
Chapter 2 Audio Front Audio Assignment Assignment Line-out Mic2-L Mic-in Mic2-R Line2-R Mic2-JD Rear Audio Line2-L Line2-JD Front Audio Rear Audio The system board is equipped with 2 audio jacks (Line-out and Mic-in). Line-in jack is optional (MOQ required). A jack is a one-hole connecting interface for inserting a plug. •... -
Page 25: I/O Connectors
Chapter 2 I/O Connectors Digital I/O Connector SATA (Serial ATA) Connectors SATA 0 SATA 1 SATA 2 SATA 3 Digital I/O The 8-bit Digital I/O connector provides powering-on function to external devices that are con- nected to these connectors. SATA 4 (opt.) Digital I/O Connector Features Assignment... -
Page 26: Cooling Fan Connectors
Chapter 2 Cooling Fan Connectors Power Connectors Ground System Fan 1 CPU Fan +12V Power Ground Power Sense Ground Speed +12V Control +12V Power Sense 12 24 +3.3V +12V +12V +5VSB PWR_OK PS_ON# +3.3V -12V +3.3V +3.3V System Fan 3 System Fan 2 Use a power supply that complies with the ATX12V Power Supply Design Guide Version 1.1. -
Page 27: Chassis Intrusion Connector
Chapter 2 Chassis Intrusion Connector Front Panel Connector Front PWR-LED Panel HD-LED ATX-SW RESET Chassis Intrusion Signal Ground HD-LED - Hard Drive LED This LED will light when the hard drive is being accessed. RESET - Reset Switch This switch allows you to reboot without having to power off the system. The board supports the chassis intrusion detection function. -
Page 28: Expansion Slots
Chapter 2 Expansion Slots Standby Power LED Standby Power LED PCIe 1 (PCIe x16) PCIe 2 (PCIe x4) PCIe 3 (PCIe x16) (opt. as 2 x8 signals) PCIe 4 (PCIe x4) M.2 2242/2280 M Key PCIe 5 (PCIe x4) (PCIe x4 NVMe, Intel Optane Momory Support)) PCI 1 Mini PCIe... -
Page 29: S/Pdif Connector
Chapter 2 S/PDIF Connector Battery SPDIF OUT SPDIF IN S/PDIF Battery The S/PDIF connector is used to connect an external S/PDIF port. Your S/PDIF port may be The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source mounted on a card-edge bracket. -
Page 30: Smbus Connector
Chapter 2 SMBus Connector LAN LED Connector LAN LED SMB_Alert SMBus SMB_CLK SMB_Data 3V3DU The LAN LED connector is used to detect the connection state of RJ45 LAN ports when the connection is made to an active network via a cable. The pin functions of the LAN LED con- nector are listed below. -
Page 31: Lpc Connector
14 13 With DFI’s proprietary technology, CS632-C246/Q370 supports two extension modules for ad- ditional four COM ports. The EXT-RS232/RS485 card is connected to CS632-C246/Q370 via the LPC connector. The illustrations below guide you how to connect the extension module to the motherboard.
