A.5 Connector Details
Audio Input
Location: Rear Panel
Conn' Type: XLR Female
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve

Instrument Input

Location: Front Panel
Conn' Type: Mono 1/4" Jack Socket
Pin Description
Tip Guitar Input
Sleeve Chassis
A.6 Physical Specification *
Depth:
Height:
Width:
Weight:
Boxed size:
Boxed weight:
* All values are approximate
A.7 Environmental Specification
As per X-Rack – see page 17.
Page A-6
200mm / 7.9 inches
275mm / 10.9 inches
171mm / 6.75 inches
35mm / 1.4 inches
49mm / 1.9 inches
260g / 9.5 ounces
190mm x 290mm x 70mm / 7.5" x 11.5" x 2.5"
460g / 16.5 ounces

Audio Output

Location: Rear Panel
Conn' Type: XLR Male
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
including front panel knobs, excluding connectors
including front panel knobs and connectors
front/rear panels
overall width (front and rear panels are offset)
