A.3 Performance Specification
The following pages contain audio performance specification figures for the X-Rack Mic Amp module. No
other Solid State Logic products are covered by this document and the performance of other Solid State
Logic products can not be inferred from the data contained herein.
A.3.1 Measurement Conditions
For each set of figures on the following pages, the specific unit and test setup will be stated at the
beginning of that section. Any changes to the specified setup for any particular figure(s) will be detailed
beside the figures to which that difference applies.
A.3.2 Measurement References
Unless otherwise specified the references used in this specification are as follows:
• Reference frequency:
• Reference level:
• Source impedance of Test Set:
• Input impedance of Test Set:
• All unweighted measurements are specified as 22Hz to 22kHz band limited RMS and are expressed in
units of dBu
• All distortion measurements are specified with a 36dB/Octave low pass filter at 80kHz and are
expressed as a percentage
• The onset of clipping (for headroom measurements) should be taken as 1% THD
• Unless otherwise quoted all figures have a tolerance of ±0.5dB or 5%
• All measurements are made with the operating level switch set for +4dBu
A.3.3 Microphone Amplifier Performance
Signal applied to Microphone Input and measured at Output. Pad switched out and Input Gain control
set to +12dB (minimum).
Gain
Input Impedance
Output Headroom
THD + Noise
(-18dBu applied, +28dB gain)
Frequency Response
Equivalent Input Noise
(input terminated with 150Ω)
Common Mode Rejection
(-10dBu applied, +30dB gain)
1kHz
0dBu, where 0dBu ≈ 0.775V into any load
50Ω
100kΩ
Continously variable from +12dB to +75dB
Independently switchable 20dB Pad available
Continously variable from ≈1k2Ω to ≈10kΩ
> +26dBu at onset of clipping
< 0.003% at 1kHz
< 0.006% at 10kHz
+0.05dB/-0.1dB from 20Hz to 20kHz
–3dB at 150kHz
< –127dB at maximum gain
< –90dB at 0dB gain (+20dB with Pad 'IN')
> 75dB from 50Hz to 1kHz
> 70dB at 10kHz
