Summary of Contents for Gold Medal 2488
- Page 1 Instruction Manual Super 88 Model No. 2488, 2489, 2488EX, 2489EX 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No. 49555...
-
Page 2: Safety Precautions
Read and understand operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862 022_060215 gmpopcorn.com... - Page 3 Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. (Gold Medal Products Co. does not assume any liability for injury due to careless handling and/or reckless operation of this equipment.) gmpopcorn.com...
-
Page 4: Installation Instructions
Super 88 Model No. 2488, 2489, 2488EX, 2489EX INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control. -
Page 5: Electrical Requirements
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns, and may cause sacrificed and/or reduced performance. -
Page 6: Controls And Their Functions
Super 88 Model No. 2488, 2489, 2488EX, 2489EX OPERATING INSTRUCTIONS Controls and their Functions LIGHT AND WARMER SWITCH Turns on the heat to the bottom corn pan and heat light. KETTLE MOTOR SWITCH Turns on the motor which drives the kettle agitator. -
Page 7: Care And Cleaning
2. Every night, mix Gold Medal’s Heat’n Kleen solution (Item No. 2095), 2 tablespoons per gallon of water. It is not necessary to use the entire gallon at once; only use enough to fill the kettle 1/2 inch deep. - Page 8 DO NOT use oven cleaners or abrasive materials as they will damage parts of the machine. 5. Clean the glass panels with glass cleaner. Gold Medal Watchdog Glass Cleaner (Item No. 2588) is recommended. Ammonia cleaners will damage the plastic doors. Use only non-ammonia cleaners, such as Gold Medal Watchdog Glass Cleaner (Item No.
-
Page 9: Maintenance Instruction
Super 88 Model No. 2488, 2489, 2488EX, 2489EX MAINTENANCE INSTRUCTION DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury or death. Read the installation, Operating, and Maintenance Instructions thoroughly before installing or servicing this equipment. DANGER Do Not immerse the equipment in water. -
Page 10: Ordering Spare Parts
Super 88 Model No. 2488, 2489, 2488EX, 2489EX ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. When ordering, please include part number, part name, and quantity needed. 3. Please include your model number, serial number, and date of manufacture (located on the machine nameplate) with your order. - Page 11 Super 88 Model No. 2488, 2489, 2488EX, 2489EX 8 oz. Kettle Assembly – 61054N Images K ettle ( 61 054 EX) A gitator ( 56 000) Complete Agitator Assembly (Includes Lids) 18, 16 Complete Agitator Assembly (Includes Lids) Complete Kettle Bottom Assembly includes...
- Page 12 Super 88 Model No. 2488, 2489, 2488EX, 2489EX 8 oz. Kettle Assembly – 61054N Parts List Part No. Item Part Description 61054N 1/4-20 X 1/2 THUMB SCREW 61059 8-32X3/8 FL HD PH MS 20065 KETTLE & SHELL BLOCK 61013 8 OZ. KETTLE SHELL...
- Page 13 Super 88 Model No. 2488, 2489, 2488EX, 2489EX 8 oz. Kettle Assembly – 61054EX Images K ettle ( 61 054 EX) A gitator ( 56 000) Complete Agitator Assembly (Includes Lids) * See Parts List note. 18, 16 26, 27...
- Page 14 Super 88 Model No. 2488, 2489, 2488EX, 2489EX 8 oz. SS Kettle Assembly – 61054EX Parts List Part No. Item Part Description 61054EX 1/4-20 X 1/2 THUMB SCREW 61059 8-32X3/8 FL HD PH MS 20065 KETTLE & SHELL BLOCK 61013 8 OZ.
- Page 15 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Cabinet Breakdown - Exterior 13, 14 2, 3 11, 12 Part Number Item Part Description Qty. 2488 2489 2488EX 2489EX DOME RED 49456 59065 49456 59065 MALE HINGE SHORT LEFT 41349 41349...
- Page 16 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Cabinet Breakdown - Interior Part Number Item Part Description Qty. 2488 2489 2488EX 2489EX CORN PAN 49211 49211 49211 49211 GLASS RETAIN STRIP, FRONT 61038 61038 61038 61038 GLASS RETAIN STRIP, REAR...
- Page 17 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Cabinet Breakdown - Interior 8, 9 Part Number Item Part Description Qty. 2488 2489 2488EX 2489EX SMALL SWITCH BOX 48501 48501 48501 48501 LIGHTED ROCKER SWITCH 42798 42798 42798 42798 DPST ROCKER SWITCH...
- Page 18 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Dome Interior - Electrical Breakdown Part Number Item Part Description Qty. 2488 2489 2488EX 2489EX LAMP HOLDER 47047 47047 47047 47047 LIGHT SHIELD CONICAL 49480 49480 49584 49584 SMALL SWITCH BOX 48501...
- Page 19 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Dome Lighting Breakdown – Model 2489 and 2489EX Part Number Item Part Description Qty. 2489 2489EX POPCORN SIGN 49575 49575 DOME RED 59065 59065 FLUORESCENT TUBE LOCK 12502 12502 LIGHT TUBE HOLDER STARTER...
- Page 20 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Accessories Part Number Item Part Description Qty. 2488 2489 2488EX 2489EX MEASURE ONE CUP 47147 47147 47147 47147 MEASURE 6.5CC (Flavacol Cup) 47678 47678 47678 47678 OIL MEASURE (1/3 CUP) 47150 47150...
-
Page 21: Wiring Diagram
Super 88 Model No. 2488, 2489, 2488EX, 2489EX WIRING DIAGRAM Model No. 2488 and 2489 gmpopcorn.com Page 21... - Page 22 Super 88 Model No. 2488, 2489, 2488EX, 2489EX Model No. 2488EX and 2489EX gmpopcorn.com Page 22...
-
Page 23: Warranty
