- Page 1 Water FOGHET stove INSTALLATION, USE AND MAINTENANCE MANUAL To be carefully kept by the owner FOGHET FOGHET With curved front With straight front WOOD version Curved or straight front...
- Page 2 The manufacturer declines any contractual or non-contractual liability for damage caused by errors in installation or use, failure to follow the instructions contained in this card, or installation in places or rooms unsuitable for the Read this card carefully and follow the instructions for quick characteristics of the product.
-
Page 3: Table Of Contents
1.1 Introduction to the Foghet water stove .................................................... 1.2 Technical specifications ..........................................................1.3 Dimensions and components ........................................................1.4 Example of combined Foghet stove with curved front installed and covered ..............................1.5 Burner and pellet hopper components ..................................................1.6 New-generation simplified electronic controller .............................................. -
Page 4: Introduction To The Foghet Water Stove
8,000 kcal/h on minimum up to 20,000 kcal/h on maximum. The Foghet with curved front can be clad as a fireplace or as a The stove can be purchased in the wood version and the burner stove (“FOGO”... -
Page 5: Technical Specifications
(they can even vary by approx. 30%). All testing, inspections and preparation of the Foghet were For optimum operation, combustion must be adjusted using the carried out using the recommended pellets. -
Page 6: Dimensions And Components
• Burn pot cleaning tool OPTIONAL SET for curved front models • Poker • Holder for accessories and removable inner door • Shovel • Removable door • Flue brush • Spring • Cleaning brush • Foghet with straight front • Foghet with curved front... -
Page 7: Example Of Combined Foghet Stove With Curved Front Installed And Covered
1.4 Example of combined Foghet stove With curved front installed and clad Fume exhaust Hood front circulation grille 40x10 cm upper edge 10 cm from ceiling Hood Lifting hook Control panel Room temperature probe for simplified controller (stand out 2 mm from wall... -
Page 8: Burner And Pellet Hopper Components
Check the position of the basket and clean it. Contact the assistance service if the problem persists. Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... -
Page 9: New-Generation Simplified Electronic Controller
4” Fig. 2 Before igniting for the second time, the level of pellets must absolutely be as shown in fig. 1 OK FOR THE IGNITION OF THE RESISTANCE Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... -
Page 10: Setting The Display Language
It is therefore necessary to carry out some corrective action to solve the problem (see par. 1.6.8). 1.6.3 Output settings for running on pellet , STANDARD control panel Foghet, during pellet burning can be set to the following output levels which are indicated on the display: Po 3 = Maximum output... - Page 11 Setting room temperature in Pellet mode, STANDARD control panel To keep the required temperature constant, the Foghet is fitted with a room temperature thermostat (standard control panel) or a room temperature probe (simplified control panel ) that automatically control the pump. Once the set room temperature has been reached, the pump switches off and the words T OFF appear on the display;...
-
Page 12: Quick Menu
If you want to use the chronothermostat in Summer as well, we recommend to set the WINTER mode, lowering the threshold for the room temperature probe at min, so that the heating doesn’t start. Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... -
Page 13: Power Output Setting For Pellet Burning Mode
If during these various attempts, the combustion gets worse instead of improving, it is possible to reset the appliance to the JOLLY-MEC factory standard settings. Resetting to factory standard settings Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... -
Page 14: How To Silence An Alarm
1" Re-enable 5” exit exit thermostat whilst timer-controlled maintaining the thermostat with memory (for the previous eventual reset) memory N.B. The chronothermostat is disabled in Summer mode. Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... -
Page 15: Use Of The Programmable Thermostat
55 C°- 65 C°. In order to have an output of 20,000 Kcal/h (23.2 kW), you need to burn 5-6 kg of wood an hour. Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner... - Page 16 2” exit (recommended (recommended 55÷75 C°) 60/75 C°) To cancel a wrong command press key 4 (ON/OFF) for one second Foghet water fireplace combined wood-pellet version with JOLLY ME 04 F burner...
-
Page 17: Ignition In Wood Burning Mode
EMPTY PAGE 1.6 New-generation simplified electronic controller 1.6.12 Ignition in wood burning mode Before lighting the pellet stove, a few preliminary operations are necessary: 1. Clean the fire bed and empty the ash pan. 2. Open the damper, turning the knob it until the notch is aligned with A, then lock it by pushing in the knob to engage the locking screw. -
Page 18: How To Optimise Combustion And Use The Damper
EMPTY PAGE 1.7 Optimising combustion and damper use This stove/boiler offers excellent performance. When using pellets, for optimum operation without overloading the burner respect the following rules, making use of the ”pellet feed control”. Step 1: manually load a small quantity of pellets using the command on the electronic controller (see F . -
Page 19: Operating Tips And Warnings
1.8 Advice and warnings IT IS IMPORTANT THAT THERE IS ALWAYS WATER IN THE BOILER AT A PRESSURE OF 1 to 1.2 BAR WHEN COLD, AND THAT THE MAINS CONNECTION FOR THE WATER REQUIRED TO COOL THE STOVE IS NEVER OBSTRUCTED. With a zone heating system, when the stove is lit, it is essential WARNING! that at least one zone of the heating system is always open in... -
Page 20: Cleaning The Stove
1.9 Cleaning the stove Initially, for a few days during operation with pellets, check the burn pot to determine how often it needs cleaning. Before any cleaning, always turn off the main switch and make sure the stove is cold. •... -
Page 21: Components That Can Be Removed For Cleaning The Stove
1.10 Parts that can be removed to clean the stove Cast iron grates Pellet burn pot Ash pan Smoke baffle Fire bed Wood guard and removable door support (curved front model only) Cleaning tools supplied Burn pot cleaning tool Shovel Poker Flue brush Small brush... -
Page 22: Plumbing Kit Components Requiring Routine Maintenance
1.11 Plumbing kit components requiring routine maintenance • Pump • Diverter valve • Pressure relief valves If the pump is locked up, to release it, remove screw 1 and turn the No maintenance required. To be cleared once a year. internal screw 2 using a screwdriver. -
Page 23: Troubleshooting
1.12 Troubleshooting WARNING! Do not use the stove if the draught is not regular and combustion is not optimum! PROBLEM CAUSE AND/OR CURE • Check for possible power supply or mains problems. The electronic controller does not • Check that the green connector of the display is correctly connected at the rear. switch on •... - Page 24 1.12 Troubleshooting PROBLEM CAUSE AND/OR CURE • THE electrical power is disconnected, reconnect it; or the controller is set to OFF; switch it on by pressing ON. • The hot water flow tap is closed; open it. • The diverter valve does not operate; check that it is connected correctly and not stuck. No hot water flows when a tap is •...
- Page 25 1.12 Troubleshooting If the stove fails to light after the second attempt, proceed as follows: 1. Remove the burn pot, loosening the locking screw with the wrench supplied or pliers. 2. Clean and scrape the sides, clean all the holes. 3.
-
Page 26: Optionals
1.13 Optionals Hood vent grille 400x100 mm Universal flue connection MF connection for Ø 150 mm double wall flexible pipe Ø 150 mm double wall flexible stainless steel flue Ø 150 mm smooth stainless steel flue Connection for Ø 150 mm rigid pipe Ø... -
Page 27: Auxiliary Large Capacity Pellet Hoppers
For a longer burn time, it is possible to install a supplementary pellet hopper, available in various capacities according to needs. The pellets can be conveyed in two ways: by auger or with pneumatic conveyance. • Pellet hopper with pneumatic conveyance Example with larger pellet hopper positioned in a room distant from the Foghet, with pneumatic conveyance. NOTE! Max. conveyance distance: 28 metres Max. -
Page 28: Pellet Quality
1.15 Pellet quality WARNING! THE QUALITY OF THE PELLETS IS VERY IMPORTANT. PLEASE READ THE NEXT PAGE CAREFULLY. IT is important to select pellets that are free of dirt and impurities. JOLLY-MEC CAMINETTI S.p.A. recommends using the same The Pellet Producers’ Association has established standards for type of pellets as those used to test the stove, since combustion producers of wood pellets. -
Page 29: Use And Conservation Of The Installation And Maintenance Manual
1.16 Use and keeping of the installation and maintenance card • Card recipients The installation and maintenance card is intended for users responsible for stove operation; particular attention must be paid the parts concerning safety. • Purpose of the card The card contains information on the correct use of the stove, according to the purposes for which it was designed and built. -
Page 30: Warranty
1.17 Warranty The Warranty Certificate is based on the Warranty Terms given below. It is valid to all intents and purposes only if sent to JOLLY-MEC CAMINETTI S.p.A. within and not later than one month from the date of purchase. All parts of the Warranty Certificate must be filled in clearly and correctly. -
Page 31: Flue
2.1 Flue The flue is an all-important element for efficient stove operation. The use of asbestos cement pipes to connect appliances to the The cross section of the flue must be that indicated in the stove flue is prohibited. technical characteristics. Every stove must have its own flue, The fume ducts must not cross rooms in which the installation excluding other emissions (stoves, boilers, fireplaces, etc.) of combustion appliances is prohibited. -
Page 32: Prearrangement For Connections And Air Inlets Of The Stove Positioned In A Corner
The positions of the holes for the fan and Caldo Control ducting can also be moved provided they remain inside the covering. For firewood-pellet Foghet stoves it is mandatory to have the three doors indicated in par. 1.4 to permit loading pellets, servicing the... -
Page 33: Prearrangement For Electrical Connections And Air Inlets With Wall Installation
The holes for the fan and Caldo Control ducting can also be moved provided they remain inside the covering. For firewood-pellet Foghet stoves it is mandatory to have the three doors indicated in par. 1.4 to permit loading pellets, servicing the... -
Page 34: Adjusting The Feet
2.4 Adjusting the feet After preparing the flue and all the electrical and plumbing connections and air intakes, as described in the previous pages, position the stove and level it, adjusting the feet with a 19 mm wrench (seeF . 1). 2.5 Damper and friction unit assembly Proceed as follows: •... -
Page 35: Caldo Control
2.6 Caldo Control The Caldo Control is a Jolly-Mec patented device enabling automatic adjustment of the primary combustion air according to the air temperature read by the bulb (F . 5) in the boiler This device gradually reduces the combustion air flow when the air temperature rises. The Caldo Control optimises stove fuel consumption, thus extending burn time. -
Page 36: Standard Plumbing Kit
2.7 Standard hydraulic kit 2.7.1 With production of domestic hot water in a sealed system Pressure relief valve discharge 3/4” Mains water inlet 1/2” Heating system delivery 3/4” Heating system return 3/4” Boiler drain... -
Page 37: Without Production Of Domestic Hot Water In A Sealed System
2.7 Standard hydraulic kit 2.7.2 Without production of domestic hot water in a sealed system Pressure relief valve discharge 3/4” Mains water inlet 1/2” Heating system delivery 3/4” Anti-condensation recirculation valve (behind check valve) Heating system return 3/4” Boiler drain... -
Page 38: Non-Standard Plumbing Kit
2.8 Non-standard plumbing kit 2.8.1 With production of domestic hot water in an open-vented system, connected to the mains water supply for domestic hot water and boiler cooling To the expansion tank with float 3/4” Temperature discharge 3/4” Hot water flow 1/2” Mains water inlet 1/2”... -
Page 39: Without Production Of Domestic Hot Water In An Open-Vented System
2.8 Non-standard plumbing kit 2.8.2 Without production of domestic hot water in an open-vented system connected to mains water supply for boiler cooling To the expansion tank with float 3/4” Pressure relief valve discharge 3/4” Mains water inlet 1/2” Heating system delivery 3/4” Anti-condensation recirculation valve Heating system return 3/4”... -
Page 40: Installation Examples
2.9.1 Installation in autonomous sealed system with production of domestic hot water Hot water flow Mains water inlet OPTIONALS FOGHET continuous flame stove Expansion tank closed Circulating pump Not included in kit Pressure relief valve set to 3.5 atm Check valve Hot water heat exchanger... -
Page 41: In A Sealed System Without Production Of Domestic Hot Water
Domestic hot water outlet Mains water inlet OPTIONALS FOGHET continuous flame stove Temperature relief valve Ball type check valve Not included in kit Pressure relief valve set to 3.5 atm Circulating pump for heating system Ball valve (mains) -
Page 42: In An Autonomous Sealed System With Thermal Cell And Solar Panels For Radiator Heating And Domestic Hot Water
2.9.4 In an autonomous sealed system with thermal cell and solar panels for radiator heating and domestic hot water Mains water inlet Room temperature probe Combined FOGHET stove Check valve OPTIONALS Pressure relief valve set to 3.5 atm Automatic pressure reducer with... -
Page 43: In An Autonomous Sealed System With Thermal Cell And Solar Panels For Production
2.9.5 In an autonomous sealed system with thermal cell and solar panels for production of domestic hot water and radiator and underfloor heating Mains water inlet Room temperature probe Combined FOGHET stove Check valve OPTIONALS Pressure relief valve set to 3.5 atm Automatic pressure reducer with... -
Page 44: Electrical Wiring Diagram For Simplified Controller
2.10 Simplified electronic controller wiring diagram DIP-SWITCH POSITION ON Room thermostat probe OFF XXXXXX Dip-switch 1 must always be set to ON ON Air heating model To control the lighting of a boiler connected in parallel, set OFF Water heating model dip-switch 3 to ON ON Relay for external boiler in parallel To control the gear motor of the supplementary pellet... -
Page 45: Purchased Product Data
2.11 Data regarding the purchased product Check that the data given in the box below correspond to that on the metal dataplate on the stove. Always give this data when requesting assistance, replacement parts and/or work under warranty. • Position of dataplate on stove Plate behind kit •... - Page 46 Notes...
- Page 48 Via Fontana, 2 - 24060 Telgate - BG - ITALY Tel. +39 035 8359211 - Fax +39 035 833389 w w w . j o l l y - m e c . i t - i n f o @ j o l l y - m e c . i t...
