Technical Data
Maximum operating pressure:
Recommended pressure:
Test pressure:
Flow rate @ 80 psi:
* For Safety, it is highly recommended that you familiarize yourself with all applicable local plumbing codes before
installing this product.
NOTE: Use your exising shower valve to operate temperature and water flow to shower panel.
• Shower Head Position
When the selector knob is placed in
a
• Jet Spray Position
When the selector knob is placed in
c

How to use

Diverter
"a"
.
"c" .
- 12 -
125psi
20~80psi
45psi ,125psi
<2.0gpm
• Hand Shower Position • Hand Shower Position
When the selector knob is placed in
b
• Dual Spray Modes
When the selector knob is placed in between two
operating, this will result in a to simultaneous
operation of both adjustment spray modes. A slight
reduction in water pressure may occur due to the
shared water flow between the two spray modes.
When the position knob is placed in
handshower and the top hydro jets will work
simultaneously.
d
"b"
.
"d" , the
