  • Page 9 English 1 General 1.1 About this document The language of the original operating instructions is French. All other languages of these instructions are translations of the original operating instructions. These installation and operating instructions are an integral part of the product. They must be kept readily available at the place where the product is installed.
  • Page 10 • If hot or cold components on the product/the unit lead to hazards, local measures must be taken to guard them against touching. • Guards which protect personnel from coming into contact with moving compo- nents (e.g. the coupling) must not be removed while the product is in operation. WILO SE...

  • Page 11: Transport And Intermediate Storage

    English • Leakages (e.g. from the shaft seals) of hazardous fluids (which are explosive, toxic or hot) must be led away so that no danger to persons or to the environment aris- es. National statutory provisions are to be complied with. •...

  • Page 12: Product Information

    DANGER! Risk of explosion! Do not use this system to lift flammable or explosive liquids. 5 Product information 5.1 Type key Example: HiDrainlift 3-35 HiDrainlift Version HiDrainlift: Standard version Product grade 1: Standard 3: Efficient 5: Premium Number of connections Delivery head Wilo SE...
  • Page 13 English 5.2 Technical data Hydraulic data HiDrainlift 3-24 HiDrainlift 3-35 HiDrainlift 3-37 Maximum delivery head Maximum Horizontal 40 m 50 m 70 m Delivery Maximum altitude 1000 m 1000 m 1000 m DN of suction connection DN40 DN40 DN40 DN of pressure connection DN32 DN32 DN32...

  • Page 14: Description And Function

    NOTE: The air cushion in the connection pipe may cause problems with flow and blockage. To prevent any blockage, the inlet pipe should be purged at its highest point. Installing the lifting unit before putting the cover back on the frame facilitates the installation and inspection of the connections. WILO SE...
  • Page 15 English Suction connection • The diameter of the suction pipe must never be less than the port on the system. 7.2 Electrical connection (Fig. 7) WARNING! Risk of electric shock! Danger from electrical current must be eliminated. • Have all electrical work carried out by a qualified electrician only! •...

  • Page 16: Maintenance

    In the event of prolonged absence, be sure to cut off the mains water supply to the house and protect the installation from freezing. Cleaning/descaling To descale and clean the lifting unit, regularly use a descaling agent specially designed to remove scale without damaging the internal components of your device. WILO SE...

  • Page 17: Faults, Causes And Remedies

    (device with lateral inlets) Flaps on lateral inlets clogged Clean the flaps, then contact an approved repair technician if necessary If you cannot remedy the fault, please contact Wilo customer service. 09/2014...

  • Page 18: Spare Parts

    English 11 Spare parts All spare parts should be ordered directly from WILO customer service. To prevent errors, always quote the data on the pump’s rating plate when making an order. The spare parts catalogue is available at: www.wilo.com. Subject to technical modifications.
  • Page 19 Mit Erhalt dieser CE-Dokumentation:  erhalten Sie die CE-Kennzeichnung für das Produkt nach der BPV.  erhalten Sie den Downloadlink für die Leistungserklärung nach der BPV: www.wilo.com/legal/ English Based on the new Regulation (EU) No 305/2011 of the European Parliament and of the...
  • Page 20 0197 WILO SE, Nortkirchenstraße 100, 44263 Dortmund - Germany 2014 (ref.) 2117926.01 PrEN 12050-3:2014 Abwasserhebeanlage für fäkalienfreies Abwasser zur begrenzten Verwendung (Produktreferenzcode) HiDrainlift 3-24 Entwässerung von Orten unterhalb der Rückstauebene in Gebäuden und auf Grundstücken, um den Rücklauf von Abwasser ohne Fäkalien in den Gebäuden zu vermeiden.
  • Page 21 0197 WILO SE, Nortkirchenstraße 100, 44263 Dortmund - Germany 2014 (ref.) 2117926.01 PrEN 12050-3:2014 Lifting plant for limited applications for faecal-free wastewater HiDrainlift 3-35 (Product’s reference code) HiDrainlift 3-37 Drainage of locations below flood level in buildings and sites to prevent any backflow of faecal-free wastewater into the building.
  • Page 22 0197 WILO SE, Nortkirchenstraße 100, 44263 Dortmund - Germany 2014 (ref.) 2117926.01 PrEN 12050-3:2014 Stations de relevage à applications limitées pour effluents exempts de matières fécales HiDrainlift 3-35 (Code de reference produit) HiDrainlift 3-37 Drainage sans reflux des points d'écoulement situés en dessous de la hauteur de refoulement dans les bâtiments et les terrains.

  • Page 23: Eg-Konformitätserklärung

    également conformes aux dispositions des normes européennes harmonisées suivantes : EN 60335-2-41 EN 55014-1+A1+A2:2011 EN 61000-3-2+A1+A2:2009 EN 55014-2+A1+A2:2008 EN 61000-3-3:2008 Dortmund, Digital unterschrieben H. HERCHENHEIN Group Quality Manager holger.herchenhein@wil o.com WILO SE Datum: 2014.09.15 Nortkirchenstraβe 100 09:30:16 +02'00' 44263 Dortmund - Germany N°2117921.01 (CE-A-S n°4192844)
  • Page 24 EZ IZJAVA O SUKLADNOSTI WILO SE vakuuttaa, että tässä vakuutuksessa kuvatut tuotteet ovat seuraavien eurooppalaisten direktiivien määräysten sekä niihin sovellettavien WILO SE izjavljuje da su proizvodi navedeni u ovoj izjavi u skladu sa kansallisten lakiasetusten mukaisia: sljedećim prihvaćenim europskim direktivama i nacionalnim zakonima: Smjernica o niskom naponu 2006/95/EZ ;...
  • Page 25 EG-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE WILO SE intygar att materialet som beskrivs i följande intyg överensstämmer WILO SE izjavlja, da so izdelki, navedeni v tej izjavi, v skladu z določili med bestämmelserna i följande europeiska direktiv och nationella naslednjih evropskih direktiv in z nacionalnimi zakonodajami, ki jih vsebujejo: lagstiftningar som inför dem:...
