Summary of Contents for weintek cMT-iPC15
- Page 1 User Manual...
-
Page 2: Table Of Contents
Other company names, product names, or trademarks in this document are the trademarks or registered trademarks of their respective companies. This document is subject to change without prior notice. Copyright© 2019 Weintek Lab., Inc. All rights reserved. -
Page 3: Overview
/ cMT-iPC10 User Manual 1. Overview cMT-iPC15 / cMT-iPC10, based on Windows® OS, can connect cMT HMI using cMT Viewer and serves as HMI, and it runs third party applications. By using cMT Launcher dedicatedly designed by Weintek R & D group, it’s easy to customize cMT-iPC15 / cMT-iPC10’s desktop into smartphone-like UI and manage access control... - Page 4 / cMT-iPC10 User Manual *Windows is a trademark or a registered trademark of Microsoft Corporation in the United States and/or other countries. *Intel Atom is a trademark of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
-
Page 5: Dimensions
/ cMT-iPC10 User Manual 3. Dimensions cMT-iPC15 54,2mm [2,13"] Top View 24,2mm [0,95"] 366mm [14,41"] 5,7mm [0,22"] Front View Side View 350mm [13,78"] 352mm [13,86"] Cutout Dimensions: 352mm [13.86"] W x 279mm [10.98"] H Rear View Panel-mounting clamp slots, 10 places... - Page 6 / cMT-iPC10 User Manual cMT-iPC10 英文版 7.9mm [0.31"] 250mm [9.84"] 260.6mm [10.26"] 36.95mm [1.45"] 250mm [9.84"] W x 192mm [7.56"] H 247.7mm [9.75"] 250mm [9.84"] VESA 75mm Screw USB Host port 2.0 Holes Power Connector LAN 2 250mm [9.84"] W x 192mm [7.56"] H...
-
Page 7: Led Indicators
The LED indicator indicates: Orange LED: Power status 5. Lithium Battery The cMT-iPC15 / cMT-iPC10 require a CR-2032 lithium battery to keep the RTC running. After replacing the battery, please enter BIOS to manually set RTC. Note: Please use CR-2032 as the replacement battery when battery runs out. Using other types of battery can cause incorrect display of time. -
Page 8: Turning On/Off The Hmi
(Or, connect a USB keyboard, and press F5 key at startup.) Note: 1. Since cMT-iPC15 / cMT-iPC10 does not offer Windows recovery disc, it is highly recommended to back up the system after installing Windows. 2. Please enter the Product Key to activate the system at the first time starting the HMI after installing the Windows Embedded Standard 7 OS;... -
Page 9: Driver
/ cMT-iPC10 User Manual OFF: To turn off the HMI, you can either turn off in Windows, or set the function of the power button in Windows Control Panel \ System and Security \ Power Options \ Change what the power buttons do, and press the power button when HMI is ON. - Page 10 / cMT-iPC10 User Manual...
