Weintek USA, Inc.
www.WeintekUSA.com
(425) 488-1100
cMT3000X Series Startup Guide
Rev. Sep 3, 2020
User
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the cMT3000X Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for weintek cMT3000X Series

Summary of Contents for weintek cMT3000X Series

  • Page 1 User Weintek USA, Inc. Manual www.WeintekUSA.com (425) 488-1100 cMT3000X Series Startup Guide Rev. Sep 3, 2020...

  • Page 2: Table Of Contents

    Table of Contents Network Wiring Diagram…………………………………………………………………………………………………………… 3 Setup……………..........................4 Web Interface....................………………………… 16 How to Use WebView………………………………………………………………………………………………………………. 23 How to Load a Project via USB Drive/SD Card ................25 How to Retrieve Historical Data via USB Drive/SD Card..............26 How to Delete All Historical Data....................27 OS Upgrade...........................

  • Page 3: Network Wiring Diagram

    1. Network Wiring Diagram Connect a cMT3000X HMI to a router by an Ethernet cable as the diagram shows below. The default IP address of LAN 1 is DHCP. The default IP address of LAN 2 is static IP 192.168.100.1. The IP addresses of LAN 1 and LAN 2 must be configured to different subnets, except for certain cMT3000X HMIs which have been activated with a Codesys license.

  • Page 4: Setup

    2. Setup Press the system toolbar button in the top left corner to open the setup menu. Information This page shows general information about cMT3000X HMI and network information.
  • Page 5 General Adjust the brightness of the screen and audio volume. Language Select a language for the system settings menu. The language selected on the project of the cMT3000X HMI won’t be changed by this setting.
  • Page 6 Input Method Select languages for system keyboard input use. Advanced Settings To access more system settings, click on the lock icon in the top left corner. There are two different levels of password protection. Select [System Setting] and enter System Setting password. The default password of System Setting is 111111.
  • Page 7 [Codesys Activation Code]- Enter the codes displayed on a Codesys activation card. Click [Active] to activate Codesys. Note: Once Codesys is activated, there is no way to remove Codesys from the cMT3000X HMI. [Restore Codesys License]- The Codesys functionality will be restored if it is enabled. Contact Weintek USA before using this.
  • Page 8 General [Direction]- Click on the button to change the direction of the screen display. [Popup download window]- If enabled, after inserting a USB disk or SD card to the slots of the cMT3000X HMI, the Upload/Download dialog window will pop up. [FTP Port]- Click the “>”...
  • Page 9 Click on a “>” button. Enable [Obtain an IP address automatically] (DHCP) or set the IP address manually (Static IP). Time/Date Adjust cMT3000X HMI RTC manually.
  • Page 10 HMI Name Change the name of cMT3000X HMI to identify this HMI when retrieving historical data or loading a project on a PC. This saves time remembering the IP address of each cMT3000X HMI. Clear History This page is used to clear historical data, recipe, and database information stored in the internal memory of a cMT3000X HMI.
  • Page 11 Project Management Restarts the project of the cMT3000X HMI and restores it to its initial state without cycling power. System Password There are three different levels of password protection, User, Update Project, and System Setting. This page is used to change the passwords for operating a project via cMT viewer, loading a project to the HMI, accessing FTP server and so on.
  • Page 12 Enhanced Security (Objects authorized to operators in HMI project) This function provides user passwords and security classes to prevent unauthorized operators from accessing objects that have the potential to cause damage or injury within your cMT3000X HMI project. For more information, refer to section 5.6.2 Enhanced Security Mode in the Easybuilder pro user manual.
  • Page 13 VNC Setting The VNC server provides remote HMI monitoring and controlling via Ethernet connection. [Start VNC]- Allows VNC connection with only one VNC client. [VNC multi connection]- Allows connection with multiple VNC clients. Connecting the VNC server to too many VNC clients may slow down the communication speed and HMI performance. [VNC login password]- Specify a password.
  • Page 14 OS Upgrade This page is used to upgrade the OS version of cMT3000X HMI. Reset Options This page is used to reset a cMT3000X HMI to its factory default settings. Press [Start] to reset if needed.
  • Page 15 Enter “yes” into the box and click on [OK] to start reset process.

  • Page 16: Web Interface

    3. Web Interface A cMT3000X HMI’s setting can also be accessed via a web browser. Before configuration, connect cMT3000X HMI (LAN1) to a router via an Ethernet cable. Open a web browser (Edge, Chrome, or Firefox) and enter the IP address of the cMT3000X HMI. For example, enter 192.168.1.15. Select an identity and enter its password.
  • Page 17 Feature Introduction Info [Now] - Synchronizes the HMI RTC with the PC RTC. Project Management [Restart Project] - Restarts cMT3000X HMI and restores it to its initial state. [Update Project]- Loads a project and recipes from the PC to cMT3000X HMI. [Backup Project]- Uploads a project from cMT3000X HMI to the PC.
  • Page 18 Email This page provides setup of the SMTP server and email contact lists. For more information, refer to section 5.11 e-Mail in the Easybuilder pro user manual. Recipe [Update]- Select a button to transfer recipe files from the PC to the cMT3000X HMI. [Backup] - Select a button to transfer recipe files from the cMT3000X HMI to the PC.
  • Page 19 Data Log & Trend Display This page displays data log information via a data spreadsheet or a trend chart. Data within each spreadsheet can be backed up individually by clicking [Export to Spreadsheet] or [Backup database]. [Export to Spreadsheet]- This function generates a CSV file. [Backup database]- This function generates a compressed file of the .db files.
  • Page 20 Event Log This page displays a data table in which operators can easily see important event information recorded on the HMI. Operation Log This page allows you to back up operation log information recorded on the HMI.
  • Page 21 Webview Setting Webview offers direct control over HMI screen using a web browser. [Set as homepage] – If enabled, Webview will be the home page of the web interface. [Change password]- Set up a password that prevent unauthorized operators from accessing Webview. [Webview]- Go to the Webview page to control the HMI screen remotely.
  • Page 22 Codesys [Status] - If activated, this tab shows Codesys network information and status information. [Project update](If activated) - Loads Codesys PLC project from the PC to cMT3000X HMI. Navigate to the folder containing *.app file and *.crc file and choose them. [CODESYS update] (If activated) - Upgrade Codesys firmware from the PC to cMT3000X HMI.

  • Page 23: How To Use Webview

    4. How to Use WebView Webview is used to monitor and control a CMT3000X HMI on a web browser. It supports the following web browsers on a Windows PC, Chrome, FireFox, and Edge. Up to 4 users can access Webview simultaneously. To use this feature, Webview must be enabled on the [Webview Setting].
  • Page 24 The HMI screen will be displayed on the web browser. Use the “square” located in the bottom right corner to scroll around the screen when zoom level exceeds 100%. The toolbar located in the top left corner contains several menus. The first group of tools allow you to enable or disable the zoom function.

  • Page 25: How To Load A Project Via Usb Drive/Sd Card

    5. How to Load a Project via USB Drive/SD Card (USB Drive ->HMI) Step 1. Use [Build Download Files] function to build *.cxob file into a USB drive or SD card. Step 2. Plug the USB drive/SD card into to the corresponding slot of cMT3000X HMI. When a pop-up window is displayed prompting you to download or upload to your device, click on [Download].

  • Page 26: How To Retrieve Historical Data Via Usb Drive/Sd Card

    6. How to Retrieve Historical Data via USB Drive/SD Card (HMI-> USB Drive) Step 1. Plug a USB drive or SD card to the corresponding slot of the cMT3000X HMI. A pop-up window will display prompting you to download or upload to your device, and then click on [Upload]. Step 2.

  • Page 27: How To Delete All Historical Data

    Step 4. Click on [Upload] to start. 7. How to Delete all Historical Data Step 1. Re-open the pop-up menu that will allow you to download or upload to your device and click on [Download]. Step 2. Enter the password and select the logs you want to delete. The password requires the levels of Update Project or System Setting.

  • Page 28: Os Upgrade

    8. OS Upgrade Step 1. Copy the new OS image to a designated folder within a USB drive. In this demonstration, I create a folder named “OS_cMT3092X,” and place the OS image into that folder. The OS image takes the form of a *.bin file.
  • Page 29 Step 7. Click the [Upgrade] button in the top right corner. Step 8. OS upgrade will begin, which may take a some time. Do not unplug the power cable during OS upgrade. It may result in all data being lost. The progress bar indicates the progress of the OS upgrade.

  • Page 30: Cmt-Viewer

    App Store V6 or greater Windows PC Weintek USA official website Windows 7 or Windows 10 (Stand-alone App. or Easybuilder pro ) Note: cMT-Viewer is installed with the Easybuilder pro package on a PC. To find it, launch the Utility Manager »...
  • Page 31 cMT-Viewer App Interface Some operation options of the cMT-Viewer App opened on different operating systems may vary. This document discusses how to operate the cMT-Viewer App running on a PC. First, launch cMT-Viewer App. Note: 1.In this demonstration, version 2.6.38 of cMT-Viewer is used. 2.Edit, Auto Play, and Page Indicator icons are only present when “Monitor Mode”...
  • Page 32 After that, the corresponding project will be loaded. If you want to go back to Connect menu, click on the Start (Home) button at the upper left corner.
  • Page 33 Add a second project to the cMT-viewer App to switch and view different projects. The small pictures of the images as shown below are images of the cMT3000X projects before leaving the projects. On [History] tab, you can connect the recently accessed projects.
  • Page 34 • Settings Menu - [Information] tab: Displays the current version of the cMT-Viewer application. [General] tab: Provides general settings. Change password- Allows users to change the password of “more settings” at the bottom left corner. Display datetime bar - Determines if the time bar will be displayed at the top of cMT-Viewer application.
  • Page 35 [Language] tab: Select a language for cMT-Viewer menus. The language selected on the project of the cMT3000X HMI won’t be changed by this setting. To enable Monitor Mode and use Password Protection functionalities, click on “more settings” icon and log in with the password set on “Change password.” The default password is 111111. There are more options available on the General tab and the Password Protection tab.
  • Page 36 [Show Start button] - If disabled, the “Home” icon on the project will be hidden. [Password Protection] - Accessing the protected actions will require a password if actions are selected below. Specify a password on [Change password] of this page. Open Project: The action to connect to cMT3000X HMI and load its project.
  • Page 37 In Password Protection mode, protected actions are locked. To access them, click on the Password Protect icon and enter the corresponding password. The protected actions are accessible to users with knowledge of assigned password. There is a countdown timer displayed as shown below. When the time runs out, the Password Protection mode will be activated.

  • Page 38: Monitor Mode

    10. Monitor Mode The small images of the cMT3000X project as shown below will be updated automatically, so users will see the latest data without entering each cMT3000X project. Click on the Auto Play button. cMT-Viewer will automatically go to the next page. To pause Auto Play mode, click the Pause button highlighted in red.
  • Page 39 When clicking on the Device Information button, the names of each cMT3000X HMI, as well as their IP address, will be displayed as shown below. Tap the “Gear” (Setup) buttons to go to the web interface of each cMT3000X HMI. Click the Edit button to configure the page layout.
  • Page 40 • Edit Menu - [Page] - Click the Add button to create a new page or delete the current page with the Delete button. Up to 9 pages can be created in each instance of cMT-Viewer. [Move the current page] - Switch to the first page, the previous page, the next page, or the last page. [Layout] - Set up the maximum number of projects in each page.
  • Page 41 6. Close [System Parameters] settings. Open the window no.3, titled Monitor Mode. 7. Place Text object, Bit Lamp object, Word Lamp object, Numeric Display object, ASCII Display object, Bar Graph object or Alarm Display object to show up-to-date data on this screen, so you can see the data shown and updated on the cMT-Viewer App while in monitor mode.

  • Page 42: Cmt-Viewer Limitations

    11. cMT-Viewer Limitations Feature Limitation Some features do not work on a cMT Viewer client (PC, iOS, Android, cMT-iV5), even if they work on the local cMT HMI. Please take this into consideration when programming projects. Features (Objects) that do not work remotely on the cMT Viewer application are listed below. •...
  • Page 43 Maximum Connect Count Three cMT-Viewer clients are allowed to remotely view and control the project of a cMT3000X HMI simultaneously by default. When the fourth cMT-Viewer client connects to the cMT3000X HMI, the warning message as shown below will pop up and reject the connection. The maximum capacity of cMT-Viewer clients can be adjusted in Easybuilder pro software.

  • Page 44: Cmt3000X Hmi Gestures Operation

    12. cMT3000X HMI Gestures Operation Tap: This is the most common gesture. Briefly touch HMI screen with fingertip. Drag: Move fingertip over HMI screen without losing contact. Press: Touch HMI screen for extended period of time. Pinch: Touch HMI screen with two fingers and bring them closer together. Spread: Touch HMI screen with two fingers and move them apart.
  • Page 45 HMI-solutions that meet the needs of all industrial automation requirements while maintaining customer satisfaction by providing “on-demand” customer service. WEINTEK LABS brought their innovative technology to the United States in 2016, WEINTEK USA, INC., to provide quality and expedient solutions to the North American industrial market.
