- Page 1 User Weintek USA, Inc. Manual www.WeintekUSA.com (425) 488-1100 cMT-3103 Wireless Network Settings Guide Rev. JAN 22 2019...
- Page 2 Table of Contents Introduction………………………………………………………………………………………………………………………….. Wireless Connection Setup via Touch Screen………………………………………………………………………… Wireless Connection Setup via Web Interface……..............System Registers…………………………………………................10...
-
Page 3: Introduction
1. Introduction cMT-3103 HMI has wireless connectivity that allows users to connect to a local wireless access point via Wi- Fi. It supports the following frequency bands, IEEE802.11b, IEEE802.11g, and IEEE802.11n. cMT-3103 HMI is equipped with one independent Ethernet port which isolates the device network from the company/factory network. -
Page 4: Wireless Connection Setup Via Touch Screen
Press the system toolbar button at the upper left of the screen to open Setup. This page shows general information about cMT-3103 HMI and network information. To access Wi-Fi settings, click on the lock icon at the top left corner. There are two different levels of password protection. - Page 5 Wi-Fi- Go to [Wi-Fi] tab and enable [Wi-Fi Radio]. Scroll up and down to select an access point and enter its password. Once the wireless connection succeeds, the status will display “Connected.” Name Descriptions Wi-Fi Radio Turn Wi-Fi radio ON or OFF. Status It shows one of the statuses including Stopped, Connecting, Retrying, or Connected.
- Page 6 You can tap the blue information icon to open the setting page of the access point. Then, set the IP address to static IP. The IP addresses of WiFi and LAN must be on the separate subnets. Click [OK] to confirm the setting.
-
Page 7: Wireless Connection Setup Via Web Interface
Configuring wireless connection of the cMT-3103 HMI via a web browser is available. Before configuration, connect cMT-3103 HMI (LAN) to a router via an Ethernet cable. Open a web browser (IE, Chrome, or Firefox) and enter the IP address of the cMT-3103 HMI. For example, enter 192.168.1.15. - Page 8 How to Switch the access point to others Click on the current wireless connection. The popup window will prompt you to disconnect the connection. Select another access point and enter its password.
- Page 9 How to set the DHCP to static IP Setting to static IP is available. To use the static IP address, click the blue information icon. Choose [Use static IP address below] and enter the IP address, mask, gateway IP, and DNS. [Join other SSID]- You can manually connect the HMI to an access point that is not displayed on the AP list.
-
Page 10: System Registers
System Registers Register No. Descriptions Associated object Readable/ Writable LW-11383(16bit) Wi-Fi control (1:Disconnected, 2:Connect, Multi-State Switch 3:Popup Wi-Fi setting dialog) LW-11384(16bit) Error code (0:No error, 1:No such device, 2:Wi-Fi Word Lamp radio is off) LW-11385(16bit) Status (0:Stopped, 1:Connecting, 2:Retrying, Word Lamp 3:Connected) LW-11386(16 words) Connected SSID... - Page 11 HMI-solutions that meet the needs of all industrial automation requirements while maintaining customer satisfaction by providing “on-demand” customer service. WEINTEK LABS brought their innovative technology to the United States in 2016, WEINTEK USA, INC., to provide quality and expedient solutions to the North American industrial market.
