- Page 1 User Manual cMT-SVR Startup Guide...
-
Page 2: Table Of Contents
2.1.1 Information ............................ 7 2.1.2 System Setting ..........................8 Chapter 3 How to create a cMT-SVR project ..................... 13 Create a new project ........................13 Download project to cMT-SVR ......................14 Chapter 4 cMT Viewer App ..........................15 Introduction of icons ........................15 How to load project file to the client device .................. -
Page 3: Chapter 1 Overview
Startup Guide Chapter 1 Overview 1.1 Specification cMT-SVR Interface Features Two Gigabit Ethernet Ports Supports E-mail Compact Design and DIN-rail Mountable Built-in 256MB Flash Memory SD Card Slot for Extension of Storage One USB Host Port ... -
Page 4: Dimensions
Startup Guide 英文版 1.2 Dimensions Top View 27,00 [1,063] 114,80 [4,520] Side View Side View Front View Bottom View USB Host Port Power Connector Ethernet 2 Port SD Card Slot Ethernet 1 Port DIP Switch Com1 RS-232, Com2 RS-485 2W/4W,... -
Page 5: Connector Pin Designations
Restore Ethernet IP settings Boot loader mode Restore factory default Note: Reboot cMT-SVR after adjusting DIP switches to start the corresponding mode. When restore factory default, the project file and history data stored in the unit are all cleared. V2.00... -
Page 6: Led Indicator
1.10 How to update cMT-SVR OS image Copy the MTfirmware.bin file to SD card, insert the SD card to cMT-SVR and flip DIP Switch 2 to ON. Restart cMT-SVR and wait about 2 minutes for the system to update OS image. -
Page 7: Requirements
Viewer App: Download cMT Viewer application from App Store or Google Play. Wireless router: The cMT-SVR connects with other devices through wires. To connect an iPad or an Android device with cMT-SVR, use a wireless router. The router is not necessary when connecting cMT-iV5. -
Page 8: Chapter 2 System Setting
Startup Guide Chapter 2 System Setting Connect cMT-SVR via Ethernet cable, and configure system settings using the following two ways. Set in internet browser Open internet browser (IE, Chrome, or Firefox), and enter cMT-SVR IP address (for example: 192.168.1.15/web_ihmi) to configure cMT-SVR. -
Page 9: Cmt-Svr System Setting
Startup Guide 2.1 cMT-SVR System Setting 2.1.1 Information The following part introduces cMT-SVR system information. V2.00... -
Page 10: System Setting
Displays RTC time. 2.1.2 System Setting The following part introduces cMT-SVR system setting. There are two modes, [System setting] and [Update]. [System Setting] controls all the settings while [Update] controls limited items. For safety, confirm password before configuring. Also, before selecting [History], enter password. - Page 11 Set the IP address of Ethernet 1 and Ethernet 2. The default IP address of Ethernet 1 is DHCP. The default IP address of Ethernet 2 is 192.168.100.1. Date/Time Set RTC time, or select [Sync with host.] to synchronize PC time with cMT-SVR. V2.00...
- Page 12 Startup Guide HMI Name Enter a cMT-SVR name to identify the unit when transferring data. This saves the trouble of remembering the IP address of each cMT-SVR. History Clear and backup history data in cMT-SVR. V2.00...
- Page 13 Startup Guide Email Set the mail address and group of the Email contact. Project Management Restart cMT-SVR project and restore to initial state, or update and backup project file. V2.00...
- Page 14 Startup Guide System Password Set the password for login, and the password for transferring project file and history file. Enhanced Security Set the privilege and password of the account. V2.00...
-
Page 15: Chapter 3 How To Create A Cmt-Svr Project
Startup Guide Chapter 3 How to create a cMT-SVR project 3.1 Create a new project Step 1. Launch EasyBuilder Pro and select cMT-SVR model. Step 2. Create the needed objects on editing screen. Step 3. Save the project and compile to *.cxob file. -
Page 16: Download Project To Cmt-Svr
The compiled *.cxob file can be downloaded by using EasyBuilder Pro via Ethernet. Or, in cMT-SVR System setting, tap Project Management \ Update Project to transfer project file from PC to cMT-SVR. Open internet browser (IE, Chrome, Firefox), enter cMT-SVR IP address (for example: 192.168.1.15/web_ihmi), tap System setting, enter password, and then configure... -
Page 17: Chapter 4 Cmt Viewer App
If needed, switch languages here. After changing the language, log in cMT Viewer App again to update the setting. Tap this icon to make cMT-SVR CPU LED (green) flash for finding the cMT-SVR. Tap this icon to load cMT-SVR project to the client device and operate. -
Page 18: How To Load Project File To The Client Device
Startup Guide 4.2 How to load project file to the client device Step 1. Start cMT Viewer App, tap Start Button as shown in the following figure. Step 2. Search all the cMT-SVRs on the same network. V2.00... - Page 19 Startup Guide Step 3. Select the cMT-SVR, tap and then enter password. Step 4. The client device displays the project after the project is loaded V2.00...
- Page 20 Startup Guide Tap Start Button to return to Search screen. To connect other cMT-SVR, follow the preceding steps to search cMT-SVR and load the project. badge is displayed in the icons of the successfully connected cMT-SVRs. Up to three cMT-SVRs can log in the client device simultaneously, and for the rest connected cMT-SVRs, the button is not available.
-
Page 21: How To Switch Between Cmt-Svr Projects
Startup Guide 4.1 How to switch between cMT-SVR projects When multiple cMT-SVRs are connected, to switch between cMT-SVR projects, select from Project tab. To delete cMT-SVR project, tap V2.00...
