- Page 1 www.setup.com.br +55 19 2517.8900 Campinas-SP-BRAZIL User Manual V1.0.0 Oct 15, 2015...
-
Page 2: Table Of Contents
Table of Contents 1. Overview ........................1 2. Specification ......................1 3. Dimensions ....................... 2 4. LED Indicators ......................3 5. Lithium Battery ......................3 6. Entering BIOS ......................3 7. Installing Windows OS ....................3 8. Turning ON/OFF the HMI ..................4 9. -
Page 3: Overview
Windows OS, can connect cMT-SVR using cMT Viewer and serves as HMI, and it runs third party applications. By using cMT Launcher dedicatedly designed by Weintek R & D group, it’s easy to customize cMT-iPC15’s desktop into smartphone-like UI and manage access control of apps. The shortcut name and icon of the application can be customized and placed in different categories and different pages. -
Page 4: Dimensions
User Manual 3. Dimensions 54,2mm [2,13"] Top View 24,2mm [0,95"] 366mm [14,41"] 5,7mm [0,22"] Front View Side View 350mm [13,78"] 352mm [13,86"] Cutout Dimensions: 352mm [13.86"] W x 279mm [10.98"] H Rear View g h i j Panel-mounting clamp slots, 10 places... -
Page 5: Led Indicators
Green LED: SSD writing status Blue LED: Ethernet communication status 5. Lithium Battery The cMT-iPC15 requires a CR-2032 lithium battery to keep the RTC running. After replacing the battery, please enter BIOS to manually set RTC. 6. Entering BIOS You can enter BIOS settings by the following two ways: •... -
Page 6: Turning On/Off The Hmi
User Manual 8. Turning ON/OFF the HMI To turn on the HMI, go to BIOS and set whether to automatically turn on, or press the power button to turn on, when the HMI is connected to power supply. Go to BIOS \ Advanced \ South Cluster Configuration \ Miscellaneous Configuration \ State After G3: S0 State: Automatically turn on when connected to power supply. -
Page 7: 10. Touchscreen Calibration
User Manual 10. Touchscreen Calibration To do touchscreen calibration, run HIDeGalaxTouch Tool. To do an advanced calibration, go to [Advanced] \ [Linearization], and choose from 9 Points or 25 Points Calibration.
