Snapper 1696000 Parts Manual page 7

Item Part No
0560 727331
0590 1733505A
0600 1733095
0610 1733509
0630 2108360
0640 1960353
0650 1736360
0680 1733192
0700 1921319
0740 7091105
0750 1960589
0760 1933896
0790 7091189
0880 7091081
0900 1960684
0910 723873
Footnotes:
Note* See your local hardware store for replacement bulbs.
24" 9TP TWO STAGE
2011
Qty Description
1 CABLE, Forward Drive
1 BRACKET, Pivot, Free Hand
1 SPACER, 1/4 ID x 3/8 OD x 1/8"
1 ROD & SPRING ASSEMBLY
1 SPRING, Compression, 2-1/4"
1 WASHER, 1/4
1 ROD, Hold Down
1 KNOB, Slot Speed
2 WASHER, 1/4
4 SCREW, Hex Washer Head, #10-16 x 1/2
1 SCREW, Phillips Head, #10-24 x 3/4
1 NUT, Hex Lock, Nylon Insert, 10-24
2 BOLT, Carriage, Curved Head, 5/16-18 x 2
2 SCREW, Hex Washer, Tap, 1/4-15 x 3/4
4 NUT, Hex KEPS, 5/16-18
4 BOLT, Carriage, Short Neck, 5/16-18 x 3/4
7
Handles & Controls Group
Manual No. 7105282
