Snapper 1696000 Parts Manual page 15

Item Part No
0100 1736379D
0120 1736038
0130 1960715
0150 1738340
0160 720064
0170 1735767
0180 2860210
0200 1733026
0210 1732412
0220 1960684
0230 1734423A
0240 1922127
0250 1738020
0260 1734439
0280 722139
0290 1960762
0300 1734542
0310 1736195A
0320 1734442
0330 1935048
0360 1931335
0370 722136
0380 95118
0390 5025391
0400 720386
0410 7012080
0420 1960093
0430 1714084
0440 1735661
0450 1735660
0460 724564
0470 724565
0480 724605
0490 1733611
0510 724579
Footnotes:
24" 9TP TWO STAGE
2011
Qty Description
1 CHUTE ASSEMBLY, Red
1 GEAR, Chute Support
3 SCREW, Truss-Head, Torx, 1/4-20 x 3/4
2 DECAL, Hinge
1 BOLT, Carriage, 5/16-18 x 1-1/2
1 GUARD, Chute Ring
2 WASHER, Nylon, 3/8
1 WASHER, 1/2 x 1-1/8 OD
1 BOLT, Shoulder, 5/16-18 X 5/8, G5
4 NUT, Hex, Conical Washer, 5/16-18
1 SUPPORT, Gear Crank
2 CAPSCREW, Hex-Head, 5/16-18 x 1-3/4, G5
1 SUPPORT, Worm, Clear
1 GEAR, Worm, Chute, L.H.
2 PIN, Hair, Chute Gear
1 NUT, Locking, 3/8-24
1 WASHER, Cup, 3/8
1 CHUTE SUPPORT ASSEMBLY
1 COVER, Gear
1 NUT, Hex-Flange, Locking, 5/16-18
1 BOLT, Carriage, 5/16-18 X 1, G5
1 KNOB, Wing 5/16-18
4 SCREW, Shoulder, Hex-Washer, 11/16
8 NUT, Nylock, 1/4-20
1 BOLT, Carriage, 1/4-20 X 3/4
2 TIE, Self-Locking
1 PUSHNUT, 3/8 Dia.
1 KNOB, Spinner, 3/8 ID, 2-3/16 OD, 2-1/2 Lg
1 CRANK, Chute Hande
1 ROD & YOKE ASSEMBLY
1 PIN, Universal Joint, 3/8 X 1
1 BLOCK, Universal Pivot
1 PIN, Cotter, 5/8 X 1/2
1 YOKE TUBE ASSEMBLY, Chute
1 PIN, Clevis, 1/4 X 1-3/16
Chute & Rotation Group - Dash Mount Crank
15
Manual No. 7105282
