Snapper 1696000 Parts Manual page 17

Item Part No
0010 12D114-0149-E8 1
0010-10 797003
0010-20 699854
0010-30 795027
0020 724865
0050 75246
0090 1739514
0100 1919381
0110 722041
0120 1733324
0130 724801
0135 1750314
0140 1737377
0150 1917356
0160 1921515
0170 1739846
0171 1931335
0172 1960684
0180 722072
0190 722457
0200 722378
0205 7091299
0210 1960251
0220 724823
0230 1739574
0240 1739964
0250 1960027
0260 1733451
0270 725367
0280 1736381
0290 1737221A
0300 1927429
0310 722455
0320 1739107D
0325 1739093A
0330 1739450D
0350 1664847
0360 1750551
0370 1751355
0390 1733868A
Footnotes:
Note* See your local Briggs & Strattion Distributor for Parts & Service.
24" 9TP TWO STAGE
2011
Qty Description
* ENGINE, 9TP Briggs & Stratton (Engine Model: 12D114-0149-E8)
1 * GUARD, Muffler
2 * SCREW, Muffler Guard
1 * CAP, Fuel
1 CORD, Electric
4 SCREW, Hex Head, Trilobular, 3/8-16 x 1-1/4
1 PULLEY
1 WASHER, 5/16
1 CAPSCREW, Hex Head, 5/16-24, 1-3/4, G5
1 V-BELT, Traction Drive, 3L, 33.13
1 BELT, Auger Drive, V4L 38.10
1 SEAL, Strip
1 STOP, Belt
4 LOCKWASHER, Spring, 5/16 (Qty 3 used on 14.5TP models)
2 CAPSCREW, Hex Head, 5/16-24 x 3/4, G5
1 BRACKET, Idler
1 BOLT, Carriage, Short Neck, 5/16-18 x 1, G5
1 NUT, Hex KEPS, 5/16-18
1 BUSHING, Idler Bracket
1 SPRING, Extension, Idler
2 IDLER
1 NUT, Hex Nylock, 3/8-16
2 NUT, Hex Centerlock Jam, 3/8-16
1 BOLT, Carriage, Short Neck, 3/8-16 x 1-1/2, G5
1 IDLER, Auger
1 SPACER, Auger Bracket
1 WASHER, 1/2
1 ARM, Control
1 PIN, Hair
1 PIN, Clevis
1 PANEL, Bottom
6 SCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8
1 SPRING, Extension, Auger
1 FRAME
1 ANGLE, Auger & Traction Rod Mounting
1 PLATE, Engine
15 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4
1 COVER, Belt
2 SCREW, Hex Washer Head, Tap, SEMS, 1/4-20 x 3/4
1 PLATE, Seal (Used on 11.5TP Models)
17
Engine & Frame Group
Manual No. 7105282
