Snapper 1696000 Parts Manual page 5

Item Part No
0010 1923701
0050 724361
0060 1918266
0070 1919439
0080 1739782A
0090 1667588
0100 1736836
0120 1921962
0130 1737684
0140 1751543
0150 1931277
0170 2820263
0180 1739487
0190 724360
0200 1917356
0230 1738286
0270 722323
0290 1931323
0300 1920397
0330 1738324
0340 1960001
0360 1750554
0370 723873
0390 1739500BZ
0400 1737544
0410 1739783A
0420 1933896
0430 1726317
0440 1736542
0450 1678392
0460 1735589
0470 1734587A
0480 1734586A
0490 1750299
0500 1737274A
0510 7035744
0515 7090391
0520 1736176
0520-10 -----
0520-20 -----
0520-30 1736180
0520-50 -----
0540 723259
0550 723154
Footnotes:
Note* See your local hardware store for replacement bulbs.
24" 9TP TWO STAGE
2011
Qty Description
1 CAPSCREW, Hex Head, 3/8-16 x 2, G5
1 SPRING, 3/4
1 WASHER, 3/8
1 NUT, Hex Lock, ESNA Light, 3/8-16
1 LEVER, Clutch, LH
1 BUSHING
1 LEVER, Speed
4 CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G5
1 BRACKET, Controls
1 ROD, Speed Control
3 NUT, Hex Flange, Whiz Lock, 5/16-18
1 NUT, Hex, 5/16-24
2 BRACKET, Mounting
1 BALLJOINT
1 LOCKWASHER, Spring, 5/16
1 WIRING HARNESS, Headlights
1 BUSHING, Chute Crank
1 BOLT, Carriage, Short Neck, 1/4-20 x 2, G5
5 NUT, Hex Lock, ESNA Light, 1/4-20
1 DASH
2 SCREW, Hex Washer Head, Plastite, 10-14 x 5/8
2 BOLT, Shoulder, 10-24
3 BOLT, Carriage, Short Neck, 5/16-18 x 3/4
1 SUPPORT, Dash
1 CABLE, Auger Drive
1 LEVER, Clutch, RH
2 NUT, Hex Lock, Nylon Insert, 10-24
2 GRIP
2 SPACER, Stepped
2 SPACER, 1/4 ID x 3/8 OD x 5/16"
1 BRACKET, Rod Support
1 HANDLE, Upper, RH
1 HANDLE, Upper, LH
2 BOLT, Carriage, Curved Head, 5/16-18 x 2-1/4
1 HANDLE, Lower
4 KNOB, Wing, 5/16-18
4 WASHER, Internal Tooth, 5/16
1 HEADLIGHT ASSEMBLY
1 LENS, Twin Light (Included in Ref. No 0520)
1 DEFLECTOR, Twin Light (Included in Ref. No 0520)
2 SOCKET & GASKET ASSEMBLY, Headlight (Included in Ref. No 0520)
2 * BULB, 12V - 20W Halogen (Included in Ref. No 0520)
1 BRACKET, Cable Adjusting
1 BOOT, Spring End Cover
5
Handles & Controls Group
Manual No. 7105282
