Gear Case Assembly - Snapper 1696000 Parts Manual

Item Part No
0300 725982
0301 725981
0303 725996
0304 725338
0305 723575
0306 724426
0310 725874
0311 724424
0312 724425
0313 1739058
0314 725983
0315 1752500
0316 725433
0320 724423
0321 724729
0322 724079
0323 724352
0324 724079
0326 724366
0327 724421
0330 724420
0340 1751535
0380 1752515
Footnotes:
24" 9TP TWO STAGE
2011
Qty Description
1 CASE, Gear, RH
1 CASE, Gear, LH
7 CAPSCREW, Hex, 5/16-24 X 1
8 NUT, Hex Flange, Serrated, 5/16-24
1 CAPSCREW, Hex Head, 5/16-24 x 1-1/2
1 PLUG, Pipe, 1/4-18
2 SEAL, Oil
2 BEARING, Sleeve, 1 x 1-1/4 x 1
2 WASHER, Flat, 1
1 SHAFT, Auger Out
1 GASKET
1 GEAR, Worm
1 KEY, Woodruf
1 RING, Quad
1 BEARING, Flange, 3/4ID x 1-1/8 OD
1 WASHER, Thrust
1 BEARING, Roll Thrust, 3/4 ID x 1-1/4 OD
1 WASHER, Thrust
1 KEY, Hi-Pro
1 WORMGEAR
1 BEARING, Sleeve, 3/4 ID x 7/8 OD
1 SHAFT, Impeller
1 RING, Retaining, 3/4"
13

Gear Case Assembly

Manual No. 7105282
