Specifications - Snapper 1632E Operator's Manual

NOTE: Specifications are correct at time of printing and are subject to change without notice.
* The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive
Engineers) code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been
obtained and corrected in accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM;
horsepower values are derived at 3600 RPM. Actual gross engine power will be lower and is affected by, among
other things, ambient operating conditions and engine-to-engine variability. Given both the wide array of products on
which engines are placed and the variety of environmental issues applicable to operating the equipment, the gas
engine will not develop the rated gross power when used in a given piece of power equipment (actual "on-site" or net
power). This difference is due to a variety of factors including, but not limited to, accessories (air cleaner, exhaust,
charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating conditions (temperature,
humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations, Briggs & Stratton
may substitute an engine of higher rated power for this Series engine.
ENGINE:
1100 Series Briggs & Stratton
Make Briggs & Stratton
Model Snow Series, M15H
Gross Torque* 11.00 ft-lbs (14.9 Nm) @ 3060 rpm
Displacement 15.2 cu. in (249 cc)
Oil Capacity 19 oz. (,56 l)
1350 Series Briggs & Stratton
Make Briggs & Stratton
Model Snow Series Max, M20H
Gross Torque* 13.50 ft-lbs (18.3 Nm) @ 3060 rpm
Displacement 18.6 cu. in (305 cc)
Oil Capacity 28 oz. (,84 l)
1450 Series Briggs & Stratton
Make Briggs & Stratton
Model Snow Series Max, M20H
Gross Torque* 14.50 ft-lbs (19.7 Nm) @ 3060 rpm
Displacement 18.6 cu. in (305 cc)
Oil Capacity 28 oz. (,84 l)
1550 Series Briggs & Stratton
Make Briggs & Stratton
Model Snow Series Max, M21H
Gross Torque* 15.50 ft-lbs (21.0 Nm) @ 3060 rpm
Displacement 20.87 cu. in (342 cc)
Oil Capacity 28 oz. (,84 l)
CHASSIS:
Wheels
- 1226, 1428, Tire Size: 15 x 5
Inflation Pressure: 20 psi (1,37 bar)
- 1530, 1632, Tire Size: 16 x 4.8
Inflation Pressure: 14 psi (,96 bar)
Spout Rotation 200 Degrees
Impeller 12 in. (30 cm) 4 Blade Ribbon Flighted Steel
Auger Opening Height 21 in. (53 cm)
Drive System Friction Disc, 6 Forward Speeds, 2 Reverse
DIMENSIONS:
Effective Clearing Width
- 1226 26 in. (66 cm)
- 1428 28 in. (71 cm)
- 1530 30 in. (76 cm)
- 1632 32 in. (81 cm)
Length
- 1226 57.5 in. (146 cm)
- 1428 57.5 in. (146 cm)
- 1530 57.5 in. (146 cm)
- 1632 57.5 in. (146 cm)
Height
- 1226 44.1 in. (112 cm)
- 1428 44.1 in. (112 cm)
- 1530 45 in. (114 cm)
- 1632 45 in. (114 cm)
Weight
- 1226 248 lbs (112 kg)
- 1428 255 lbs (116 kg)
- 1530 255 lbs (116 kg)
- 1632 260 lbs (118 kg)
33

Specifications
