Section 1 - Familiarization - Snapper ZF2100DKU, ZF2300GKU, ZF5200M, ZF6100M Safety Instructions & Operator's Manual

Section 1 - FAMILIARIZATION

MOTION
CONTROL
(JOYSTICK)
CONTROL PANEL
(SEE INSET)
DECK HEIGHT OF
CUT DECAL
DISCHARGE
DEFLECTOR
1.1 INTRODUCTION
This manual has been prepared for the operator's of the
SNAPPER OUT FRONT Z-RIDER. Its purpose, aside
from recommending standard operating procedures and
routine service requirements, is to promote SAFETY
through the use of accepted operating practices. Read,
Understand and Follow the IMPORTANT SAFETY
INSTRUCTIONS on Page 2 and 3 of this manual and All
SAFETY messages on the OUT FRONT Z-RIDER and its
attachments before operating. SNAPPER recommends
returning the OUT FRONT Z-RIDER to an authorized
SNAPPER dealer annually for inspection and addition of
any new devices which might upgrade the safety of the
mower.
OPERATOR'S SEAT
FIGURE 1.1
1.2 NOMENCLATURE
The nomenclature information above, Figure 1.1, shows
the essential parts of the SNAPPER OUT FRONT Z-
RIDER. It is recommended that all operator's of this
equipment become thoroughly familiar with the controls,
components, and operation of this machine before
operating.
found in the separate engine owner's manual. Study
these manuals before operating and keep both handy
for future reference. For the nearest SNAPPER dealer
in your area, check the yellow pages under the heading
LAWN MOWERS. For engine parts and service, look
for the engine manufacturer's dealers under the
heading, ENGINES - gasoline.
5
CONTROL PANEL
AMP
IGNITION
METER
SWITCH
HOUR
METER
FUEL TANK
PARKING BRAKE
ENGINE SPEED
CONTROL
Specific details involving the engine are
BLADE SWITCH
DECK
LIGHT
LIFT
SWITCH
SWITCH
DECK COVER
CASTER
WHEEL
BRACKET
