Snapper ZF7302M Parts Manual
  1. Manuals
  2. Brands
  3. Snapper Manuals
  4. Lawn Mower
  5. ZF7302M
  6. Parts manual
Snapper ZF7302M Parts Manual

Snapper ZF7302M Parts Manual

73” ofz mower unit for out front z-rider
Hide thumbs

Advertisement

Table of Contents

IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS
POSSIBLE AND PRATICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE
CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY
OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED
PREVIOUSLY.
COPYRIGHT © 2000
SNAPPER INC.
ALL RIGHTS RESERVED
Parts Manual for
73" OFZ MOWER UNIT
FOR OUT FRONT Z-RIDER
MANUAL No. 4-7173 (REV. 1, 5/31/00)
MODELS
ZF7301M
ZF7302M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZF7302M and is the answer not in the manual?

Questions and answers

Related Manuals for Snapper ZF7302M

Summary of Contents for Snapper ZF7302M

  • Page 1 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRATICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.

  • Page 2: Table Of Contents

    CONTENTS Page Description/Group 3 _______________________________ FAMILIARIZATION – 73” OFZ MOWER UNIT 4, 5 _____________________________ 73” OFZ MOWER DECK ASSEMBLY 6, 7 _____________________________ DECK FRAME ASSEMBLY 8, 9 _____________________________ REAR CASTER ASSEMBLY 10, 11 ___________________________ FRONT CASTER ASSEMBLY 12 ______________________________ FIXED IDLER GROUP 13 ______________________________ ROLLER ASSEMBLY 14 ______________________________ SPRING-LOADED IDLER GROUP 15 ______________________________ SPINDLE GROUP...

  • Page 3: Familiarization – 73" Ofz Mower Unit

    FAMILIARIZATION - 73” OFZ MOWER UNIT MANUAL No. 4-7173 73” OFZ MOWER UNIT...
  • Page 4 73” OFZ MOWER DECK ASSEMBLY (For Components Breakdown see Pages as Indicated) MANUAL No. 4-7173 73” OFZ MOWER UNIT...
  • Page 5 BOLT, 3/8-16 x 1” Carriage, Grade 5 (4) 9-1299 NUT, 3/8-16 Hex Top Lock (4) 4-1896 BELT, 165.16” HB Section (ZF7301M) 7-3328 BELT, 153.12” HB Section (ZF7302M) 4-6623 BRACKET, Rear Deck Hanger (2) 9-1640 BOLT, 3/8-16 x 1” Carriage Grade 5 GROUP, Fixed Idler (See Page 12)
  • Page 6 DECK FRAME ASSEMBLY NOTE: UNLESS OTHERWISE NOTED, ALL FLATWASHERS ARE ITEMS 4 (22 TOTAL), AND ALL COTTER PINS ARE ITEMS 10 (16 TOTAL). MANUAL No. 4-7173 73” OFZ MOWER UNIT...
  • Page 7 DECK FRAME ASSEMBLY ITEM PART NO. DESCRIPTION 4-7171 PLATE, Diamond Tread Foot 9-1523 SCREW, 5/16-18 x 5/8” Hex Self-Tapping (8) 9-0219 SCREW, 5/16 x 2-1/2” Hex Head Cap (4) 9-1587 WASHER, 17/32 Flat (22) 4-3803 BRACKET, Deck Lift Hanger (2) 4-6595 ARM, Front Lift (Weldment) 4-7130...
  • Page 8 REAR CASTER ASSEMBLY 1 - COMPLETE MANUAL No. 4-7173 73” OFZ MOWER UNIT...
  • Page 9 REAR CASTER ASSEMBLY ITEM PART NO. DESCRIPTION 5-7738 ASSEMBLY, Rear Caster, 73” OFZ Deck (Includes items 2 thru 16) 1-7711 PIN, 7/16” Lynch 1-9152 SPACER, Caster (6) 2-1960 SPACER, 1 x 1-3/8 x 19/64” 2-2151 SPACER, Axle Sleeve 2=3556 BUSHING, Caster (2) 2-3747 BUSHING, 1”...

  • Page 10: Front Caster Assembly

    FRONT CASTER ASSEMBLY 1 - COMPLETE ASSEMBLY MANUAL No. 4-7173 73” OFZ MOWER UNIT...
  • Page 11 FRONT CASTER ASSEMBLY ITEM PART NO. DESCRIPTION 5-7774 ASSEMBLY, 11” Front Caster (Includes items 2 thru 14) 1-2709 RING, 1” External Retaining 1-3864 FITTING, 3/16 Lube 2-3556 BUSHING, Caster 2-3747 BUSHING, 1” Machine 2-9141 BEARING, Flanged Ball 3-5359 TUBE, 5/8” O.D. x 3-35/64 Long 4-6620 YOKE, Caster (Weldment) 4-7138...

  • Page 12: Fixed Idler Group

    FIXED IDLER GROUP ITEM PART NO. DESCRIPTION 5-4355 ASSEMBLY, Fixed Idler Group 3-5789 PULLEY, 5 1/2” O.D. Idler 3-6449 STAND, Fixed Idler 9-1299 NUT, 3/8-16 Hex Top Lock (4) 9-1300 WASHER, 7/16 Flat 9-1305 SCREW, 3/8-16 x 2” Hex Head Cap 9-1640 BOLT, 3/8-16 x 1”...

  • Page 13: Roller Assembly

    ROLLER ASSEMBLY ITEM PART NO. DESCRIPTION 5-4695 ASSEMBLY, Roller (2) (Includes items 2 thru 15) 2-1960 SPACER, 1” x 1-3/8 x 19/64 (2) 2-3747 BUSHING, 1” Machine 4-4646 CASTER, Gage Wheel (Weldment) 4-4752 SPACER, 3/8 x 3/4 4-4839 CAP, Caster Shaft 5-4702 ASSEMBLY, Gage Wheel Caster (Weldment) 7-9868...

  • Page 14: Spring-Loaded Idler Group

    SPRING – LOADED IDLER GROUP IDLER ARM ASSEMBLY ITEM PART NO. DESCRIPTION 5-4356 ASSEMBLY, Spring-Loaded Idler Group (Includes items 1 thru 18) 5-4248 ASSEMBLY, Idler Arm (Includes items 3 thru 14) 4-2619 ARM, Idler (Weldment) 2-3556 BUSHING (2) 7-6998 FITTING, 1/4-28 Straight 3-2031 WASHER, 1-1/32 Flat 1-2709...

  • Page 15: Spindle Group

    SPINDLE GROUP ITEM MANUAL No. 4-7173 PART NO. DESCRIPTION 9-1736 NUT, 5/8-18 Hex Flange Lock, Grade 5 2-9270 WASHER, Spindle 2-9249 PULLEY, 5-3/4” O.D. 2-9274 SNAP-RING, Spindle Shaft 2-9422 BEARING, Sealed (2) 2-9302 BOLT, 3/8-16 x 1-1/4” Rib Necked (6) 2-9252 HOUSING, Cutter 9-1299...
  • Page 16 Parts Manual for 73” OFZ MOWER UNIT FOR OUT FRONT Z-RIDER ZERO TURNING HYDRO DRIVE MODELS ZF7301M ZF7302M COPYRIGHT © 2000 SNAPPER INC. ALL RIGHTS RESERVED MANUAL No. 4-7173 (REV. 1, 5/31/00)
