Snapper SERIES 20 Parts Manual page 9

Item Part No
1 7500081
1 7400029
1 7500549
2 7091508
3 7091601
4 7046780
5 7090324
6 7074568
7 7091214
8 7015780
9 7090201
10 7101414
11 7026691
12 7012063
13 7090167
14 7015626
15 7026407
16 7029149
17 7090189
18 7101022
19 7011791
20 7024340
21 7090951
22 7091169
23 7044770
24 100602-0155-B8
24 121Q72-0110-F1 1
24 126L02-4113-F1
24 126T02-0267-B1 1
24 128L02-0114-F1
24 12S502-0112-B1 1
24 12S507-0115-B1 1
24 12S602-0110-F1 1
24 12S902-0126-B1 1
24 12S907-0127-B1 1
24 12S972-0152-B1 1
24 12S977-0153-B1 1
24 121S72-0111-F1 1
Footnotes:
NOTE: * Purchase engine parts from engine manufacturer dealer.
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 WELDMENT, Deck, 21" Non-Adjust Air (red, w/o decals) (used on "R" (recycling) models)
1 WELDMENT, Deck, 21" Push, HV, Core Model (red, w/o decals) (used on 7800428 & 7800437
(push) models)
1 WELDMENT, Deck, Part Sales, Hi-Vac, ES (red, w/decals) (used on self-propelled (non-
recycling) models)
1 BOLT, 5/16-18 x 3/4" Short Neck Carriage GR 5 (was 7090001)
2 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7091070)
2 PLUG, Hole, Polyethylene
3 SCREW, 3/8-16 x 1" Self-Tapping (engine mount bolts)
1 COVER, Belt
1 KEY, Woodruff #HP-506 Hi-Pro
1 PULLEY, Engine (25mm I. D. x 2-1/8" O.D.)
1 SET SCREW, 5/16-18 x 5/16" Hex Socket (or 7092086 (SET SCREW, 5/16-18 x 1/2" Hex
Recess))
1 HUB, Blade, 21" WBM, RD, 2 Position
1 BLADE, 21" Standard Lift
2 WASHER, Cone 3/8"
1 SCREW, 3/8-24 x 2" Hex Head Cap, GR 5
1 HUB, Blade Drive, 25 mm I.D.
1 BLADE, 21" Ninja (Quad Edge) (Used on Recycling Models)
1 COVER, 21" Deck
2 WASHER, 5/16" Internal/External Lock
2 KNOB, Fluted, 5/16-18 x 1/2"
1 RETAINER, 5/16" Bolt
1 SPACER,.316 ID x .375 OD x .310 thick
1 NUT, 5/16-18 Hex Large Flange Center Lock
1 BOLT, 5/16-18 x 1-1/8" Round Head Short Square Neck, GR 5, ZP
3 SPACER, Blade Hub (Used on 7800427 & 7800553)
1 * ENGINE, B&S DOV 700 Series (used on 7800424 (RP217020BDV))
* ENGINE, B&S 875 Professional Series, California Compliant (used on 7800692 (NP2187520))
1 * ENGINE, B&S 675 Series (used on 7800437 & 7800438
* ENGINE, B&S 675 Series (used on 7800428 & 7800429)
1 * ENGINE, B&S 700 Series, California Compliant (used on 7800600 & 7800601)
* ENGINE, B&S 875 Series, Intek (used on 7800425, 7800430 & 7800492)
* ENGINE, B&S 875 Series, Intek (used on 7800432 & 7800427)
* ENGINE. B&S 875 Series, Snapper, XIC, F1 (used on 78000439 (NP2187520BV))
* ENGINE, B&S 875 Series, W14 (used on 7800552 & 7800554)
* ENGINE, B&S 875 Series, W14, ES (used on 7800553 & 7800555)
* ENGINE, B&S, 875 Series, W14 w/oil fltr, 49 ST (used on 7800754 & 7800758)
* ENGINE, B&S, 875 Series, W14 w/oil fltr (used on 7800759)
* ENGINE, 875 Series, Snapper California Compliant (used on 7800771)
Engine, Cutting Deck & Blade
9
Manual No.
7006477
