Snapper SERIES 20 Parts Manual page 21

Item Part No
-- 7053943
1 7053942
2 7029034
3 7012314
4 7073963
5 7029035
6 7024442
7 7014155
8 7053939
9 7029033
10 7090189
11 7051903
12 7092062
13 7019213
14 7092063
15 7091825
16 7016544
17 7091720
18 7090557
19 7031970
20 7050767
21 7031965
22 7012500
23 7021115
24 7011110
25 7012495
26 7050831
27 7090376
28 7011774
29 7050830
30 7012543
31 7011724
-- 7061017
Footnotes:
NOTE: * Maximum capacity of transmission before causing leakage is 4 oz. DO NOT OVERFILL!
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 ASSEMBLY, Transmission (Incl. items 1 thru 31)
1 ASSEMBLY, Right Housing (Incl. items 2 thru 7) (or 7051908)
1 HOUSING, Right Side
2 SEAL, 5/8" Internal Diameter
1 BALL BEARING, 7/16 I.D., 1/1/8" O.D.
2 BEARING, Tapered (Differential Housing)
3 GASKET, 5/8" O. D.
3 SCREW, 5/16-24 x 1-1/8" Rib Neck, GR 5
1 ASSY, Left Housing (Incl. items 3, 5 & 9) (was 7053938)
1 HOUSING, Left
3 WASHER, 5/16" Internal/External Tooth Lock
1 WELDMENT, Differential Bracket
4 NUT, 5/16-18 Hex Lock (was 7011201)
1 PULLEY, Poly-V Belt (3.5" O.D.)
1 WASHER, Cone
4 SCREW, 1/4-20 x 1" Hex washer Self-Tap (was 7092064)
1 PLUG, Transmission Housing
1 WASHER, .453 x .75 x .073 Flat, YZ
4 SCREW, #10-32 x 1-1/2" Hex Head Cap GR 5
2 PLATE, 46T Gear
1 ASSEMBLY, Input Gear
2 WASHER, Thrust, 3/4" I.D.
4 SPACER, Pinion Gear
4 GEAR, Pinion (12 tooth)
4 SHAFT, Pinion
1 GEAR, Differential (46 Tooth)
1 ASSEMBLY, Long Axle (was 7051933)
4 NUT, #10-32 Hex Nyloc
1 GASKET, Housing
1 ASSEMBLY, Short Axle (was 7051932)
1 SPACER, Axle Gear
1 WASHER, 44 x .78 x .025 Curved
4 oz. * "00" Grease, 32 oz bottle (not shown)
21
Transmission (Differential)
Manual No. 7006477
