Snapper SERIES 20 Parts Manual page 15

Item Part No
1 7500038
1 7051885
2 7051886
3 7054247
4 7054246
5 7011393
5 7031016
6 7015761
7 7011791
8 7012325
9 7100633
10 7031017
11 7032723
12 7011078
13 7035717
14 7032722
15 7100752
15 7021119
16 7091601
17 7900018
18 7100196
19 7012312
20 7091012
Footnotes:
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 ASSEMBLY, Front Left Wheel Arm (.512" Square Hole)
1 ASSEMBLY, Front Left Wheel Arm (.453" Square Hole) (used on 7800427 only)
1 ASSEMBLY, Front Right Wheel Arm
1 ASSEMBLY, Wheel Arm Left Rear Long SP21S
1 ASSEMBLY, Wheel Arm, Right Rear (S.P.)
1 WHEEL ARM, L.H. Front (.512" Square Hole)
1 WHEEL ARM, L.H. Front (.453" Square Hole) (used on 7800427 only)
2 BOLT, 5/16-18 x 3/4" Hex Washer Face Shoulder
4 RETAINER, 5/16" Bolt
2 LATCH, Height
4 GRIP, Height Latch
1 WHEEL ARM, R.H. Front (Round Hole)
1 ARM, Wheel, Left Rear
2 BOLT, 5/16-18 x 1" Hex Washer Face Shoulder
2 LATCH, Height Adjusting (long)
1 ARM, Wheel, Right Rear
1 AXLE, Front, Easy Line (3/8-16 Threads)
1 AXLE, Front, (7/16-20 Threads) (used on 7800427 only)
4 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7090585 or 7091070)
2 SCREW, Round Washer Head Torx, Hi-Lo
1 COVER, Front 21" walk
2 BEARING, 9/16" I.D.
6 SCREW, #10-32 x 3/8" Hex Washer Self-Tap
Wheel Brackets & Latches (Self-Propelled)
15
Manual No.
7006477
