Snapper SERIES 20 Parts Manual page 5

Item Part No
1 7074411
2 7023810
3 7074418
4 7034872
5 7074156
6 7033985
7 7033986
8 7074140
8 7074469
8 7073826
9 7091200
10 7074473
11 7028407
12 7023792
13 7014343
14 7091020
15 7079577
16 7034608
16 7102593
16 7078078
17 7090053
18 7091576
19 7023813
20 7074460
20 7100975
20 7102594
21 7075308
22 7090505
23 7028488
24 7076978
25 7034604
26 7012121
27 7012122
28 7026219
29 7091189
30 7012080
31 7090391
32 7023153
33 7074003
34 7091305
35 7031961
36 7028465
37 7074113
Footnotes:
NOTE: * Part number and revision is stamped on cable.
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 HANDLE, Upper
1 FOAM GRIP, 18.75" long
1 BAIL, OPC Control
1 CLIP, Zone Control
1 HANDLE, Middle
1 HANDLE, Lower LH (Adjustable)
1 HANDLE, Lower RH (Adjustable)
1 CONTROL PANEL (w/o Electrical Switch Hole) (Used on Manual Start Models)
1 CONTROL PANEL (w/Electrical Switch Hole) (Used on Electric Start models)
1 CONTROL PANEL (w/o wheel drive slot) (used on 7800428 & 7800437)
4 SCREW, 1/4-20 x 1/2" Pan Head Self-Tap (Torx)
1 HANDLE, Clutch
1 GRIP, International Symbol
1 PIN, 1/4 x 1-1/2"
2 BUSHING, .27 x .35 x .4 Flange
1 PUSH-NUT, 1/4"
1 SCREW, 1/4-20 x 1-1/2" Hex Head Cap GR 5
1 * CABLE, Zone Control (52-63/64" Long) (used on 7800425, 7800428, 7800429, 7800437,
7800596, 7800597 & 7800602)
1 * CABLE, Zone Control (52-21/32" Long) (used on 7800424, 7800552, 7800553, 7800554,
7800555, 7800754, 7800758, 7800759 & 7800771)
1 * CABLE, Zone Control (50-31/64" Long) (used on 7800427 & 7800432 models only)
5 WASHER, 1/4" Internal Tooth Lock (was 7091023)
3 NUT, 1/4-20 Hex (was 7091100)
1 CLIP, Wiring Harness
1 THROTTLE CONTROL, (48.5") (used on all models except for those shown below)
1 THROTTLE CONTROL, RP, D.O.V. Engine (50.0") (used on 7800424 model)
1 THROTTLE CONTROL, (62.0") (used on 7800552, 7800554, 7800555, 7800553, 7800754,
7800758, 7800759 & 7800771)
1 THROTTLE KNOB, (Red)
2 SCREW, 1/4-20 x 2" Hex Head Cap, GR 5
1 GUIDE, Rope (1/4-20 thread)
1 NUT, 1/4-28 Hex GR 5 or B
1 CABLE, Clutch Control (41-1/4" Long)
1 COVER, Vinyl
1 SPRING, Clutch - 21S
1 CLAMP, 7/8" Double Cable
4 SCREW, 5/16-18 x 1-7/8" Curved Head GR 2 (was 7091740)
2 CABLE-TIE, 7"
4 WASHER, 5/16" Internal Tooth Lock
1 CLAMP, Casing
1 BRACKET, Shift
1 SCREW, 3/8-16 x 2" Hex Head Cap, GR 5
2 WASHER, 7/16" Flat
2 WASHER, Nylon
1 LEVER, Shift
5
Handles and Controls
Manual No.
7006477
