Snapper SERIES 20 Parts Manual page 13

Item Part No
1 7500038
2 7051886
3 7501119
4 7054228
5 7011393
6 7015761
7 7011791
8 7012325
9 7100633
10 7031017
11 7102587
12 7011078
13 7035717
14 7033776
15 7100752
16 7091601
17 7900018
18 7100196
19 7103210
Footnotes:
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 ASSEMBLY, Left Wheel Arm (.512" Square Hole)
1 ASSEMBLY, Right Wheel Arm
1 ASSEMBLY, Wheel Arm, Left Rear Long (Push)
1 ASSEMBLY, Wheel Arm, Right Rear (Push)
1 WHEEL ARM, L.H. Front (.512" Square Hole)
2 BOLT, 5/16-18 x 3/4" Hex Washer Face Shoulder
4 RETAINER, 5/16" Bolt
2 LATCH, Height
4 GRIP, Height Latch
1 WHEEL ARM, R.H. Front (Round Hole)
1 ARM, Wheel, Left Rear
2 BOLT, 5/16-18 x 1" Hex Washer Face Shoulder
2 LATCH, Height Adjusting (long)
1 ARM, Wheel, Right Rear
2 AXLE, Front, Easy Line (3/8-16 Threads)
4 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7090585 or 7091070)
2 SCREW, Round Washer Head Torx, Hi-Lo
1 COVER, Front 21" walk
1 GUARD, Rear (21 Push)
Wheel Brackets & Latches (Push)
13
Manual No.
7006477
