Grass Bag Components - Snapper SERIES 20 Parts Manual

Item Part No
1 7500153
2 7100433
3 7042489
4 7051906
5 7090189
6 7091527
7 7047082
8 7091601
9 7072107
10 7013860
11 7012306
12 7091508
13 7011791
14 7024340
15 7090951
16 7047081
17 7101022
18 7024228
19 7058037
20 7016814
Footnotes:
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 BAG ASSEMBLY, (Door) (includes items 2, 3 & 4)
1 GRASS BAG, (Door) No Graphics
1 CONNECTOR, Grass Bag (weldment)
1 ASSEMBLY, Bag Wire (12" Wide)
2 WASHER, 5/16" Internal/External Tooth Lock
1 SCREW, 5/16-18 x 1-1/4" Hex Head Cap (was 7091984)
1 BRACKET, Rope Guide
2 NUT, 5/16-18 Hex Flange Lock, GR 5 (was 7091070)
3 WASHER, 15/32" Flat
3 RIVET, 3/16 x .344
1 BUSHING, Flange, .381 x .625 x .62
3 BOLT, 5/16-18 x 3/4" Short Neck Carriage GR 5
3 RETAINER, 5/16" Bolt
1 SPACER, .316 I.D. x .375 O.D. x .310 thick
1 NUT, 5/16-18 Hex Large Flange Center Lock
1 ADAPTER, Grass Bag
2 KNOB, Fluted, 5/16-18 x 1/2"
1 PULLEY, Nylon
1 ASSY, Grass Bag Adapter (includes items 6, 7, 8, 9, 10, 11, 16 & 18)
1 PLUG, Chute Adapter
27

Grass Bag Components

Manual No. 7006477
