Snapper SERIES 20 Parts Manual page 17

Item Part No
1 7091542
2 7090391
3 7034179A
4 7011724
5 7012354
6 7091576
7 7090053
8 7012616
9 7091604
10 7029008
11 7023791
12 7090289
13 7091122
14 7031809
15 7011025
16 7028014
17 7031873
18 7012316
19 7024521
20 7091630
21 7090390
22 7012111
23 7012126
24 7091025
25 7012124
26 7090303
27 7012122
28 7091597
29 7072284
30 7012125
31 7300977A
32 7090122
33 7041855
34 7010746
35 7026693
36 7091294
37 7074145
38 7090673
39 7090095
40 7015753
41 7046784
42 7073528
43 7013893
43 7017696
Footnotes:
21"STEEL DECK WALK BEHIND MOWERS
SERIES 20
Qty Description
1 SCREW, 5/16-18 x 1/2" Pan Head Self-Tap (Torx)
1 WASHER, 5/16" Internal Tooth Lock
1 LINK, Differential (Comm.)
1 WASHER, 44 x .78 x .025 Curved
1 BELT, Poly-V
1 NUT, 1/4-20 Hex, GR 5 (was 7090063)
1 WASHER, 1/4" Internal Tooth Lock (was 7091023)
1 SUPPORT, Foot Guard
1 BOLT, 1/4-20 x 1/2" Short Neck Carriage GR 5 (was 7090005)
1 FOOT GUARD, Rear
1 RING, Split (Black)
1 NUT, 3/8-24 Hex Center Lock, GR 5
2 SCREW, 1/4-20 x 1/2" Hex Flange Self-Tap (was 7090539)
1 HOLDER, Bearing (Outer Half)
1 O-RING, V21
1 BALL BEARING, Spherical O.D., .38 I.D.
1 HOLDER, Bearing (Inner Half)
1 WASHER, .390 I.D. Flat
1 PULLEY, Poly-V (2" O.D.)
2 NUT, 3/8-24 Hex
3 WASHER, 3/8" Internal Tooth Lock
1 STUD, Idler (3/8-24 thread)
1 SPRING, Idler- Torsion
1 SCREW, 1/4-28 x 1-3/8" Hex Head Cap, GR 5
1 PULLEY, Idler, V21
1 NUT, 1/4-28 Hex Top Lock
1 SPRING, Clutch - 21S
1 COTTER PIN, 3/32 x 1/2" (was 7090555)
1 SHAFT, Hex Drive
1 GUIDE, Thrust Plate (3/8-24 thread)
1 THRUST PLATE, Short (was 7034281)
1 WASHER, 3/8" Flat
1 DISC, Driven (Cantilever) (ref: 7074139, Driven Disc Ass'y)
2 RETAINING RING, .625 External
1 BALL BEARING, 3/4" Bore (was 7029027)
1 WASHER, .28 x .63 x .06 Flat
1 LINK, Transfer (1/4-28 thread)
1 COTTER PIN, .06 x .50 YZ (was 7091629)
2 NUT, 1/4-28 Hex (see Handles & Controls page (item 58))
1 BALL JOINT, 1/4-28 (also shown on Handles & Controls Group page)
1 BELT, Engine Drive (Stretch)
1 DRIVE DISC, Steel
1 BUSHING, Powdered Metal (used for 1992 and earlier models)
1 BUSHING, Powdered Metal (used for 1993 and later models)
17
Drive System Self-Propelled
Manual No. 7006477
