Safety Instructions and Operator's Manual for
MODEL DESIGNATION
MODEL TYPE
MODEL OPTION
S – Snapper Commercial Model
P – Pro Mid Size Model
E – Express Model
L – Loop Traction Controls
Thank you for buying a SNAPPER Product! Before operating your PRO GEAR WALK BEHIND, read this manual
carefully and pay particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 - 4. Remember that all
power equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
COPYRIGHT © 2000
SNAPPER INC.
ALL RIGHTS RESERVED

WALK BEHIND MOWERS

MODEL NUMBER EXPLANATION
S
P
EL
ENGINE HORSE POWER
15 – 15.0 Engine HP
PRO GEAR EXPRESS
15
0
CUTTING DECK WIDTH
361 – 36" Cutting Deck
481 – 48" Cutting Deck
MID-SIZE
SERIES 0

POWER UNIT

MODEL
SPEL150KH

MOWER UNIT

MODEL
SPE361
SPE481
KH
SERIES DESIGNATION
0
Series Designation
KH – Kohler Engine
-
MANUAL No. 7-3316 (I.R. 8/29/00)
ENGINE TYPE
ENGINE HP
