LEGEND:
B1 -
Temperature Display
B2 -
Airflow Level Display
C1 -
Temperature Control (Up)
C2 -
Temperature Control (Down)
C3 -
Airflow Control (Up)
C4 -
Airflow Control (Down)
F
-
Hot Air Gun Function Switch
G
-
Airflow Gauge
H
-
Vacuum pen
Connector
(for i852A++ only)
6
CONTROL PANEL GUIDE
B1
C2
C1
B2
C3
C4
Main Power Switch
AC Power Inlet with
Fuse
v
Back Panel
F
G
H
