- Page 1 ® AOYUE 899A+ SMD REWORK STATION INSTRUCTION MANUAL Thank you for purchasing Aoyue Int899A+ SMD REWORK STATION. It is important to read the manual before using the equipment. Please keep manual in accessible place for future reference.
- Page 2 To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recy- cling. Manufacturer: AOYUE INTERNATIONAL LIMITED Jishui Industrial Zone, Nantou, Zhongshan City, Guangdong Province, P.R.China http://www.aoyue.co...
- Page 3 This manual is designed to familiarize and instruct the operator with the proper usage and maintenance of the equipment. The “Care and Safety Precautions” section explains the hazards of using any type of soldering or reworking device. Please read carefully and observe the guidelines in order to maximize usage and minimize the risk of injury or accidents .
- Page 4 PACKAGE INCLUSIONS 1 unit 899A+ Main Station with Hot Air Gun AT-8 nozzle set (T1196, T1197,T1313) B004 Soldering Iron 2660 Soldering Iron Stand Hot Air Gun Holder IC Popper Power Cord Instruction Manual ** Kindly refer to soldering iron stand installation on page 6 for parts and instructions.
- Page 5 SAFETY PRECAUTIONS CAUTION: Improper usage can cause serious injury to personnel and/or damage to equipment. For your own safety, please observe the ff. precautions. ● Check each component after opening the package to make sure everything is in good condition. If there are any suspected damage, do not use the item and report the issue to your vendor.
- Page 6 INSTALLATION PROCEDURE A. Hot air gun holder: . Remove the two screws on the top right surface of the machine. 2. Install the Hot air gun holder at the top right surface of the unit. 3. See Figure 1 for the proper positioning of the holder. 4.
- Page 7 OPERATING GUIDE A. HOT AIR GUN REWORKING Plug the power cord. Turn on the upper right hand switch. Digital readout of current temperature will appear. Adjust temperature and airflow according to the type of component being reworked. NOTE: If reworking plastic or larger components, higher tempera- ture and airflow is needed.
- Page 8 22mm 22mm SERIES SERIES Replacement Air Nozzles MODEL＃ IC SIZE L(mm) W(mm) SGL SERIES MODEL＃ IC SIZE L(mm) W(mm) A(mm) B(mm) 1010 9×9mm 1131 4.4×10mm 10.3 1313 12×12mm 1616 15×15mm 1132 5.6×13mm 11.7 1919 18×18mm 1133 7.5×15mm 2828N 27×27mm 1134 7.5×18mm 3030N 29×29mm...
