ASSEMBL Y and PREPARATIONS
(FOR Int 852A++ pro only)
Align the vacuum pen holder
legs with the two screw holes.
IMPORTANT REMINDERS:
1. Make sure the equipment is placed on a flat stable surface
and all the heat-generating components placed on their re-
spective holders or stands.
2. Ensure all function switches are OFF prior to reworking.
3. Ensure all terminal connections are properly secured.
IMPORTANT: Please refer to the CONTROL PANEL GUIDE page for
A. INITIAL PROCEDURES
1. Plug the device to the main power source using the power cord
provided in the package.
2. With all function switches deactivated and all terminal connections
properly secured, switch ON the device by activating the main power
switch.
3. The display panels, B1 and B1 will temporarily show the product name
in a scrolling manner and then display "OFF" on all rows once the
scroll is finished. The system will remain at this state until the user
activates a function.
8

OPERATING GUIDELINES

buttons and display panel directory.
Loosen the two screws that on the side
of the station.
Fasten the
screws.
two
