X K 3 1 9 0－C 602
AQNL 000.000 1C
AQAD 2 27
AQFL 2 28
AQFm 1 0A
AQSt 2 05
AQ0T 1 45
AQ0S 1 42
AQ0I 4 5D
AQEI 1 2D
AQUt 2 03
Note 3 of Table E-2: Codes of working parameter: MG instrument working mode; Lt display illumination;
ZX main display content; FX auxiliary display content; Ad instrument communication address; Pr printer type; PL
printer language; 1C working mode of serial port 1; 2C working mode of serial port 2; 1B baud rate of serial port 1;
2 B serial port 2 baud rate; Ao weight relevant to full measuring range of analog output; FA DA code of full
measuring range of analog output; 0A DA code of analog output zero; DA definition of analog output; EA
switch of analog output; 1E switch of serial port 1; 2E switch of serial port 2; EP switch of printer; AP automatic
printing switch; AM automatic storage ; EB large screen switch; Pf parameters number; 0Z zero area; T0~T7
timing constant T0~T7; P1~P8 batching value, refer to Table E-4. CY cycling times: Tq switch of lead
modification; Cc out-of-tolerance treatment switch; Db gradual feed switch; Ff peak value holding switch. Refer to
Table E-5 for returned data and explanation
Code
P1
P2
P3
P4
P5
P6
P7
P8
Table E-5 Explanation of Returned Setting Parameter Data of Instrument
Returned data of
instrument
ARMG 2 2B
ARLt 5 1E
ARZX 0 21
ARFX 4 39
ARAd 01 37
zero)
Non-linear modification value 0
AD transfer speed 2 ：60cps
Filtration strength 2
Filtration method 1
Stable judgment 2
Zero tracking range 1：0.5e
Zero setting range 1：
Initial zero setting range 4：20%
Initial zero setting switch 1：on
Weight unit 2：kg
Table E-4 Meanings of Working Parameter Codes P1~P8
Quantitative scale
A1 batching of material 1
B1 quick feed lead of material 1
C1 slow feed lead of material 1
D1 allowance of material 1
A2 batching of material 2
B2 quick feed lead of material 2
C2 slow feed lead of material 2
D2 allowance of material 2
Equipment type 2: automatic control of catchweigher
Display illumination 5
Main display content 0: weight
Auxiliary display content 4: work step (operation
state)/time (non operation state)
Communication address 01
Catchweigher
A upper limit of channel 1
B upper limit of channel 2
C upper limit of channel 3
D upper limit of channel 4
——
——
——
——
Explanation
