INSTRUCTION MANUAL
ROTEX AIR PRO
®
S.E.F.A
Z.I PASTABRAC
11260 ESPERAZA
FRANCE
Tel: +33 (0)4.68.74.05.89 - Fax: +33 (0)4.68.74.24.08
E-mail:
contact@sefa.fr
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROTEX AIR PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Sefa ROTEX AIR PRO

  • Page 1 English version V0916 INSTRUCTION MANUAL ROTEX AIR PRO ® S.E.F.A Z.I PASTABRAC 11260 ESPERAZA FRANCE Tel: +33 (0)4.68.74.05.89 - Fax: +33 (0)4.68.74.24.08 E-mail: contact@sefa.fr Page 1...
  • Page 2: Table Of Contents

    English version V0916 INDEX WARRANTY TERMS ........................3 TECHNICAL DATA .......................... 4 III. WEAR PARTS ..........................4 USING THE PRESS ......................... 5 SETTING UP THE MACHINE ........................ 6 Unpacking ..............................6 TRANSFER CYCLE ..........................6 CONTROL PANEL ..........................7 OPERATION ............................8 Presets .................................
  • Page 3: Warranty Terms

    English version V0916 I. WARRANTY TERMS • The warranty period shall come into effect on the day on which the equipment is brought into service at the user's premises, as attested on the returned warranty certificate and the delivery note, and shall run for two years, based on a standard equipment operating schedule of 8 hours per day, i.e.
  • Page 4: Technical Data

    English version V0916 II. TECHNICAL DATA ROTEX AIR PRO 97kg Weight in working order 41kg Height 681 mm Depth 940 mm Width 624 mm Platen size 400 x 500 mm Power supply 230 V Single phase + Earth 50/60 Hz...
  • Page 5: Using The Press

    English version V0916 IV. USING THE PRESS This heat press has been designed for small production runs without risk to operator safety in accordance with article L 233-5 of the French labour code. Pressure gauge Electronic board and pneumatic components TOUCH SCREEN Main switch control panel...
  • Page 6: Setting Up The Machine

    English version V0916 A. SETTING UP THE MACHINE 1. Unpacking 1. Remove the packing case from the machine. 2. Set up and secure the machine on its work table. 3. Make sure the press is cold before picking it up. Carry the press holding both platens (upper and lower), which should be in the closed position.
  • Page 7: Control Panel

    English version V0916 C. CONTROL PANEL Time Date Heating indicator Current Presets temperature reading and temperature adjustment field Main timer Increment-up, open next menu, browse presetting sub-menus Increment-down, open previous menu, browse presetting sub-menus Settings menu key Resettable counter Page 7...
  • Page 8: Operation

    English version V0916 D. OPERATION Presets This menu contains nine pre-saved operating programs; up to five presets can be assigned to each program by entering the required setpoints. The operating programs must be suited to the processes you use. The temperature adjustment system is fine- tuned for each program.
  • Page 9: Settings Menus

    English version V0916 Settings menus Press the green key in the centre of the screen to open the settings. Click to access the required menu. Press the arrow in the bottom centre of the screen to exit. End-of-cycle beeper time User comfort settings setting Sleep mode...
  • Page 10: Machine Settings

    English version V0916 Machine settings Enable drying mode The drying time is set at the control panel with the pressing time setpoint User comfort settings °C/°F Enable/disable buzzer Machine operating temperature range Energy saving mode Energy saving mode reduces the machine temperature to the set temperature when the defined idle time has elapsed.
  • Page 11: Auto-Swing

    English version V0916 E. AUTO-SWING When the cycle ends, the heat platen will lift up and the auto-swing system will rotate the press away to the side, free of the heat platen. You can disable this feature if you wish. To enable this feature, first make sure the press is in the open position, then turn and push the thumbwheel down as shown on the diagram below.
  • Page 12: Maintenance

    English version V0916 F. MAINTENANCE • Daily: Clean the heat platen with a dry cloth. • According to use: Replace the silicone foam pad at the first sign of damage or deterioration in quality. Page 12...
  • Page 13: Troubleshooting Tips

    English version V0916 V. TROUBLESHOOTING TIPS The machine’s electrical power must be switched off and locked and tagged prior to any service repair work. The heat platen can cause burns. Check that the platen temperature reading on the display panel is below 25°...
  • Page 14: Wiring And Pneumatic Diagrams

    English version V0916 VI. WIRING and PNEUMATIC DIAGRAMS Page 14...
  • Page 15 English version V0916 Page 15...
  • Page 16: Maintenance Log

    English version V0916 VII. MAINTENANCE LOG The following checks and maintenance procedures should be performed at regular intervals to ensure that your press remains in good working order and continues to provide reliable service. Condition Heating Number Pressure Air filter Cylinder Replaced Date...
