Table 6 describes the ports for the MACH-ProWebCom controller. These ports are user
configurable within the MSet utility.
T 6: MS
ABLE
Port
HTTP
Resource
Service
Passive Service
P S
ORT ETUP
PC/M
ODEM
F 32: PC/M
IGURE
Baud options are 9600, 19200, 38400, 57600, and 115200.
If provided, the PTP Password field is required to be given by any BACnet PTP device
connecting to the port.
Enabling the Initiate PTP Connection checkbox instructs the MACH-Pro(Web)Com to
attempt a BACnet PTP connection every 2 minutes until a successful connection has been
made. If the checkbox is unchecked (default), the MACH-Pro(Web)Com passively waits for
a connection to be made from an external device.
The Modem Configuration button opens the Modem Configuration dialog box which
provides serial port settings to use when initiating a dial-out from Control-BASIC. This is
especially useful when using the APDIAL statement for alphanumeric pagers which
typically use the 7-E-1 setting.
®
 2007 − 2015 Reliable Controls
Corporation. All rights reserved.
MACH-P
ET PORTS AND FUNCTION FOR THE
Description
The MACH-ProWebCom controller listens for Web requests from a
browser on this port (default is 80).
RC-Studio and RC-Toolkit use this port to issue transfer
commands to the MACH-ProWebCom (default is 21).
RC-Studio and RC-Toolkit use this port range to transfer data to
and from the MACH-ProWebCom (default is 3000–3020).
ODEM GROUP
MACH-P C
RO OM
W C
RO EB OM
™ /MACH-P W C ™
RO EB OM
Configuration
U G
SER UIDE
