Glow-worm HYBRID COMPACT System Manual page 27

Key
1 Heat pump controlled by On/Off contact
2 Heat pump circuit fi lter
3 Cylinder
3.1 Temperature sensor 2K7 at 25°C (high position)
3.2 Temperature sensor 2K7 at 25°C (low position)
4 Electric domestic hot water back-up heater
5 Wireless outdoor sensor
6 Heat pump control unit
7 Electrical power and protection of the heat pump
8 Electrical power and protection of the back-up heater
9 Systempro control unit
10 Electrical power and protection of the module
11 Climapro , Climapro RF or Climapro
1 1
12 Hydraulic module
13 Heating circuit (UFH shown, but can be underfl oor or radiators)
14 Overheating safety (if underfl oor heating)
15 Glycol PRV discharge
16 Domestic hot water option 3-way valve
C Heat pump circuit fl ow
D Heat pump circuit return
E Heating circuit return
F Heating circuit fl ow
G Heat pump circuit safety valve discharge
H Cold water supply
I Domestic hot water fl ow
X Not used
Application conditions
- The Systempro control unit manages the operation of the
boiler, the heat pump and the module.
- The heat pump command unit is used as a setting or
diagnostic tool.
- The room thermostats compatible with the system are the
for "wireless" versions and the
Climapro RF or Climapro RF
2 1
for the "wired" version.
Climapro
1
- The installation must include a wireless outside sensor.
- Connect the heat pump On/Off directly to the control box.
- The overheating safety must be connected according to the
standards in force (on the boiler or the circulation pump).
- The installation can be performed with a low-temperature
underfl oor heating (heating outlet temperature < 50°C) or low
temperature radiators (heating outlet temperature < 70°C).
0020153648_01 - 02/13 - Glow-worm
RF room thermostat
2
Domestic hot water:
- The Systempro control unit controls the 3-way valve and the
domestic hot water temperature in the tank.
- The non-powered 3-way valve must leave the heating circuit
open. With the valve powered, the heating circuit will be
closed and the circuit to the domestic hot water tank will be
open.
Control unit settings
Description of main settings
Hot water tank option
Heat pump control unit settings
∙ Refer to the heat pump installation manual to access the
"After-sales" parameters listed below.
Menu Name of the function
112 Heating curves (*)
114 ECO heating mode (*)
(*) Refer to the correspondence table in the "Settings > Heating"
section.
SYSTEM MANUAL
Setting
2 sensors T°
Setting
7 - 12
1 - 20°C
- 27 -
