Glow-worm HYBRID COMPACT System Manual page 15

Key
1 eBUS heat pump
2 Heat pump circuit fi lter
3 Hydraulic module
4 Electrical power and protection of the heat pump
5 Wireless outdoor sensor
6 Systempro control unit
7 All brands of boiler controlled by 24V ON/OFF contact
8 Climapro , Climapro RF or Climapro
1 1
9 Heating circuit (UFH shown, but can be underfl oor or radiators)
10 Non-return valve (recommended to prevent burner ignition triggered
by thermo-siphoning)
11 Overheating safety (if underfl oor heating)
12 Glycol PRV discharge
13 Domestic hot water cylinder not managed by the Systempro
A Heating circuit fl ow
B Heating circuit return
C Domestic hot water fl ow
D Domestic hot water return
E Heat pump circuit fl ow
F Heat pump circuit return
G Heat pump circuit safety valve discharge
Application conditions
- The Systempro control unit manages the operation of the
boiler, the heat pump and the module.
- The hydraulic connections to the boiler must be suitable for its
characteristics.
- Boiler must have a 24V thermostat input.
- The room thermostats compatible with the system are the
Climapro RF or the Climapro
2
the Climapro for the "wired" version.
1
- The installation must include a wireless outside sensor.
- Connect the heat pump e-BUS directly to the control box
respecting the polarity (+/-).
- Connect the boiler directly to the control box.
- The overheating safety must be connected according to the
standards in force (on the boiler or the circulation pump).
- The installation can be performed with a low-temperature
heated fl oor (heating outlet temperature < 50°C) or low
temperature radiators (heating outlet temperature < 70°C).
0020153648_01 - 02/13 - Glow-worm
RF room thermostat
2
RF for "wireless" versions and
1
Connecting the boiler
If a room thermostat is already connected to an existing boiler,
remove it.
Check whether the room thermostat is connected to a boiler 24V or
230V input.
24V = Connect the boiler 24V
thermostat input to the "OUT1"
connector of the control unit.
In the case of an existing boiler without external sensor:
Increase the boiler heating outlet temperature by 5°C.
Ensure that the heating outlet temperature does not exceed 70°C (50°C
in the case of a underfl oor heating).
In the case of an existing boiler with external sensor:
Keep the existing boiler heating curve if the comfort of the existing
installation is satisfactory.
Ensure that the heating outlet temperature does not exceed 70°C (50°C
in the case of a underfl oor heating).
Important: the setting of the control unit heating curve must be identical
to that of the boiler.
OK
Put the installation into service.
SYSTEM MANUAL
230V = Refer to the "Diagram
13" section.
NOK
Ensure that the heating outlet
temperature does not exceed
70°C (50°C in the case of a
underfl oor heating).
> If the adjustment is not
available on the boiler, perform
it on the thermostatic valve.
> If there isn't a thermostatic
valve, install a temperature
control device to make this
adjustment.
- 15 -
EN
