  • Page 1 HYBRID COMPACT System Installation Dual-energy system for heating and hot water www.glow-worm.co.uk...

  • Page 3: Table Of Contents

    System description ..........................3 Concept of operation ....................3 Example of Installation – Diagram 9 (9.1) : HYBRID COMPACT with 1 low heating temperature zone (30-40°C) or 1 high heating temperature zone (< 80°C) ... 4 Example of Installation – Diagram 9 (9.2) : HYBRID COMPACT with 2 low heating temperature zones (30-40°C) or 2 high heating temperature zones (<...
  • Page 4 TABLE OF CONTENTS C O M MI SSI ON IN G Filling the glycol circuit ........................15 Filling the heating circuit ........................16 Activating the heat pump .........................16 Activating the boiler ..........................16 Activating the room thermostat ......................16 Activating the control unit .........................16 12.1 Confi...

  • Page 5: Introduction

    System description Concept of operation Instructions guidance The hybrid system consists of the following components: - A Glow-worm Envirosorb 5 heat pump, Product documentation - A "Compact" hydraulic module, The instructions are an integral part of the system appliances and must be handed to the user on completion of the - A boiler, installation in order to comply with the current regulation.

  • Page 6: Example Of Installation - Diagram 9 (9.1) : Hybrid Compact With 1 Low Heating Temperature Zone (30-40°C) Or 1 High Heating Temperature Zone (< 80°C)

    INTRODUCTION Example of Installation – Diagram 9 (9.1) : HYBRID COMPACT with 1 low heating temperature zone (30-40°C) or 1 high heating temperature zone (< 80°C) This diagram shows the case of an installation with Refer to the chapters “Hydraulic connection” and a single zone low temperature heating fl...

  • Page 7: Example Of Installation - Diagram 9 (9.2) : Hybrid Compact With 2 Low Heating Temperature Zones (30-40°C) Or 2 High Heating Temperature Zones (< 80°C)

    INTRODUCTION Example of Installation – Diagram 9 (9.2) : HYBRID COMPACT with 2 low heating temperature zones (30-40°C) or 2 high heating temperature zones (< 80°C) This diagram shows the case of an installation with a Refer to the chapters “Hydraulic connection” and dual zone low temperature heating fl...

  • Page 8: Example Of Installation - Diagram 9 (9.3) : Hybrid Compact With 3 Low Heating Temperature Zones (30-40°C) Or 3 High Heating Temperature Zones (< 80°C)

    INTRODUCTION Example of Installation – diagram 9 (9.3) : HYBRID COMPACT with 3 low heating temperature zones (30-40°C) or 3 high heating temperature zones (< 80°C) This diagram shows the case of an installation with Refer to the chapters “Hydraulic connection” and a three zone low temperature heating fl...

  • Page 9: Safety Instructions And Regulations

    The adhesives and sealants used in this appliance are cured and give no known hazard in this state. The refrigerant used in this appliance is R410a the use of which is strictly controlled by F Gas regulation EN842/2006. 0020096883_01 - 06/10 - Glow-worm - 7 -...

  • Page 10: Installation

    - an anti-sludge fi lter (if necessary). for additional advice. • In the case of a heated fl oor, install a manual reset overheat safety device (55°C) on the heating circuit fl ow (refer to the 0020096883_01 - 06/10 - Glow-worm - 8 -...

  • Page 11: Mounting

    2 shut-off valves in order to be able to remove it from the circuit and clean it periodically. • Connect the fl ow heat pump circuit (2). • Connect the return circuit (5) to the heat pump. 0020096883_01 - 06/10 - Glow-worm - 9 -...

  • Page 12: Boiler Circuit

    • Connect a pipe (2) to the fl ow connection (1) leading away from the boiler. • Refer to the boiler instructions to connect the pipes (2) and (4) to the boiler. 0020096883_01 - 06/10 - Glow-worm - 10 -...

  • Page 13: Heating Circuit

    Return heating connection (Ø ¾") leading to the hydraulic module Return heating tubing leading to the hydraulic module (not included) • Connect a pipe (2) to the return connection (5) leading to the hydraulic module. 0020096883_01 - 06/10 - Glow-worm - 11 -...

  • Page 14: Electrical Wiring

    • Connect the cable (3) to the NTC1 terminal in the Systempro control. • Connect the Ebus cable to the Systempro control unit. • Tighten the clamp (4). • Tighten the clamp. 0020096883_01 - 06/10 - Glow-worm - 12 -...

  • Page 15: Boiler

    EBUS connectors (2 pins) (3). • Connect the power supply to the 230 V connector (4) following the instructions given on the connector. • Tighten the power cable (1) in the anti-tamper connector (3). 0020096883_01 - 06/10 - Glow-worm - 13 -...
  • Page 16 REL1 REL2 REL3 REL4 REL5 - Diagram 9 (9.1) : HYBRID COMPACT with 1 low heating temperature zone (< 40°C) or 1 high heating temperature zone (< 80°C) When the 2 port valve is connected to REL3: Description Cable min.

  • Page 17: Commissioning

    Any residue of glycol solution should be kept in an appropriate container to be re-used for the next fi lling. • Ensure any leftover glycol solution is left with the end user and retained in a safe place. 0020096883_01 - 06/10 - Glow-worm - 15 -...

  • Page 18: Filling The Heating Circuit

    Switch On (I) / Off (O) • Turn on the control unit (1) with the switch (2) in position (I). Make sure the boiler pump is not in permanent mode. 0020096883_01 - 06/10 - Glow-worm - 16 -...

  • Page 19: Confi Guring The Installation

    • If this is not the case and the installation has only one zone, choose "NO" with the buttons • Press the button to confi rm. 0020096883_01 - 06/10 - Glow-worm - 17 -...

  • Page 20: Wiring Summary

    • Using the buttons , select • Using the buttons Outdoor sensor on the screen. select Rmstat/sensor on the screen. • Press the button to confi rm. • Press the button to confi rm. 0020096883_01 - 06/10 - Glow-worm - 18 -...

  • Page 21: Self Check

    (+/- 5 ° C, at intervals of 1 ° C - factory setting: 0). • Using the buttons select External T ºC correction on the screen. • Press the button to confi rm. 0020096883_01 - 06/10 - Glow-worm - 19 -...

  • Page 22: Settings

    Older properties with radiators Standard/modern house with radiators Highly insulated modern house with low temperature radiators or underfl oor heating Heating fl ow temperature (°C) External temperature • Press the button twice. 0020096883_01 - 06/10 - Glow-worm - 20 -...
  • Page 23 - the price exc VAT per ton of propane gas. buttons to display the • Enter the information and the values in the tables below. desired value. • Press the button to confi rm. 0020096883_01 - 06/10 - Glow-worm - 21 -...
  • Page 24 0,0526 to 0,0550 0,0551 to 0,0575 0,0576 to 0,0600 0,0601 to 0,0625 0,0626 to 0,0650 0,0651 to 0,0675 0,0676 to 0,0700 0,0701 to 0,0725 0,0726 to 0,0750 0,0751 to 0,0775 0,0776 to 0,0800 0020096883_01 - 06/10 - Glow-worm - 22 -...

  • Page 25: Commissioning

    • Select Fill htg circuit on the screen • Press the button using the buttons • Press the button to confi rm. When venting is complete, close the different heating circuit air vent. 0020096883_01 - 06/10 - Glow-worm - 23 -...
  • Page 26 Available pressure (kPa) Flow within the circuit (l/h) • Confi rm with the button order to begin the venting process. You can start the heating circuit bleed at the same time. 0020096883_01 - 06/10 - Glow-worm - 24 -...
  • Page 27 • Press the button to confi rm. • Using the button , launch the reading of the heat pump circuit fl ow. Speed control Speed I Speed II (not applicable to this system) 0020096883_01 - 06/10 - Glow-worm - 25 -...

  • Page 28: Status Reports

    • To access the information relative to the components, press and confi rm with the button • Press the button to consult a fault report. • To reset the fault report press and confi rm with the button 0020096883_01 - 06/10 - Glow-worm - 26 -...

  • Page 29: Options

    - the temperature of the room in which the room thermostat is located, - whether the heating zones respond to a demand (ON or OFF), - the status of the 2-way valve (ON or OFF). 0020096883_01 - 06/10 - Glow-worm - 27 -...

  • Page 30: Heating System Test

    • Follow the indications on the control unit screen and consult the "Troubleshooting" chapter for the corresponding failure code. 0020096883_01 - 06/10 - Glow-worm - 28 -...

  • Page 31: Re-Check And Restart

    - The user shall not interfere with or adjust sealed components. - Any servicing must be carried out by a competent person approved at the time by the Health and Safety Executive. 0020096883_01 - 06/10 - Glow-worm - 29 -...

  • Page 32: Status

    • Consult the heat pump installation manual for information 15.3.2 Heat pump status about the fault codes. • Consult the heat pump installation manual for information about the status codes. 0020096883_01 - 06/10 - Glow-worm - 30 -...

  • Page 33: Servicing

    This menu allows you to issue a heating demand to the boiler. • Press the button • Press the button to activate the heating demand. • Press the button to disable the heating demand. • Press the button 0020096883_01 - 06/10 - Glow-worm - 31 -...
  • Page 34 • Press the button to activate the test. The domestic hot water cylinder 2-way valve opens and the heat pump heats the domestic hot water cylinder circuit. • To disable the test, press the button 0020096883_01 - 06/10 - Glow-worm - 32 -...
  • Page 36 Because of our constant endeavour for improvement, details may vary slightly from those shown in these instructions. Glow-worm, Nottingham Road, Belper, Derbyshire. DE56 1JT...
