- Page 1 Product Instruction Manual ARCW (white) & ARCBSS (brushed stainless steel) 1.25kW Automatic Hand Dryer Version 3.2 Jan 2015 V17.6/1...
-
Page 2: Important Safety Points
Thank you for purchasing a Hyco Arc hand dryer. Please ensure you read and understand these instructions to ensure safe installation and operation. The arc is a high speed, automatic hand dryer that is suitable for a variety of public washroom applications. - Page 3 2. Installation To avoid malfunction do not install the appliance in the following: Temperatures below -10 C or above 40 C. Locations exposed to direct sunlight or strong light. • When selecting a suitable location and surface for installation of the dryer, consider the following: •...
- Page 4 Recommended mou (bottom edge of dry 43” 41” • Drill the 4 x holes in each corner as shown and insert the wall plugs. 39” 33” Always ensure no concealed electrical wiring or pipework prior to drilling into the surface. •...
- Page 5 figure 2 Fuse Power switch UV light Power 230V~ Indicator Temperature probe Sensing probe CONTROL RELAY MOTOR Temperature switches Heater Thermal fuse • Ensure the supply cord is well secured to the dryer using the provided cable clamp. • Ensure the internal power switch is set to the “ON” position. •...
- Page 6 3. Operation • Shake off excess water from washed hands. • Place hands under the hand dryer to initiate air flow. • Slowly move hands under the air flow. • Turn over hands and repeat. • Rub hands together until sufficiently dry. •...
-
Page 7: Specifications
5. Specifications ARCW ARCBSS Voltage 230V~ 230V~ Power 1250 watts 1250 watts IP Rating IPX1 IPX1 Finish White Brushed stainless steel Weight 3.2kg 3.2kg 255mm 150mm 173mm... - Page 8 If you experience a problem with this product you should first contact our service department on 01924 225 200 before taking any further action. Experience has shown that issues can often be resolved without the need to return or uninstall the product. Hyco Manufacturing Ltd Normandy Court Express Way Castleford, WF10 5NR...
