Hyco HD1800 Instruction Manual

EYK0254 Hyco Hurricane Man:EYK0254 Hyco Hurricane Man
3.

OPERATION

• Shake excess water from hands.
• To activate the hand dryer, place your hands underneath the air outlet to
operate the sensor.
• Rub hands together lightly and rapidly.
• The dryer will stop automatically 1 second after removing hands.
• The dryer will also automatically cut-out after 1 minute of consecutive use.
• To re-start the hand dryer, put
hands back underneath and re-
operate the sensor.
• The sensitivity of the sensor can be
adjusted by removing the cover and
accessing the Printed Circuit Board
(see fig 5)
Fig 5
4.

CLEANING AND MAINTENANCE

• Clean using a soft, damp cloth.
5.

SPECIFICATIONS

• Voltage: 230v-50Hz
• Rated Power: 1800W
245mm
9.7"
• Current: 7.8A
• Universal Brush Motor 5600rpm
• Air Speed: 17.8m/s
• IP Rating: IPX1
• Weight: 4.1kg
16/11/07 07:39 Page 1
6.

GUARANTEE AND SERVICE POLICY

The Hyco Hurricane is supplied with a standard 12 month replacement
warranty (excluding Lamps) that protects against any manufacturing defects
for up to 1 year of the original purchase date. In the event of a product
failure please contact Hyco on 01977 517555. Incidental or consequential
damages are excluded from this warranty.
Adjustable
resistance
Please adjust
carefully
263mm
10.4"
245mm
9.7"
Schematic diagram
HURRICANE
HAND DRYER
HD1800
Instruction Manual
website: www.cnmonline.co.uk Tel: 0844 884 2900
