- Page 1 Product Instruction Manual PR SM PRMW, PRMBSS 0.9kW Automatic Hand Dryer Version 3.2 Jan 2015 V17.11/1...
-
Page 2: Important Safety Points
Thank you for purchasing a Hyco Prism hand dryer. Please ensure you read and understand these instructions to ensure safe installation and operation. The Prism is a high speed, automatic hand dryer that is suitable for a variety of public washroom applications. - Page 3 2. Installation To avoid malfunction do not install the appliance in the following environments: Temperatures below -10 C or above 40 C. Places directly sprinkled by water. Places in direct sunlight or strong light. Within 40cm of any surface beneath the air outlet. •...
- Page 4 • Remove the dryer cover via the 2 x counter sunk screws, located at opposite sides of the cover (Allen key tool provided). • Before mounting the dryer to the surface, make provisions for the wiring. • For concealed wiring via a junction box, it is necessary to knock out the provided circle in the back plate.
-
Page 5: Electrical Connection
3. Electrical connection Always isolate the power supply before any electrical work or wiring of the dryer. • Connection should be made to the fixed wiring of the property via a double pole switched fused spur. • Electrical connections should be made as follows: Green/Yellow earth wire to the terminal marked “... - Page 6 4. Operation • Shake of excess water from washed hands. • Place hands under the dryer outlet to initiate air flow. • Slowly move hands under the air flow. • Turn over hands and repeat. • Rub hands together until sufficiently dry. •...
-
Page 7: Specifications
6. Specifications PRMW PRMBSS Voltage 230 ~ 230 ~ Power 0.9kW 0.9kW Ingress rating IP22 IP22 Finish 73db White Brushed stainless steel Weight 3.4kg 3.4kg 300mm 250mm 169mm... - Page 8 If you experience a problem with this product you should first contact our service department on 01924 225 200 before taking any further action. Experience has shown that issues can often be resolved without the need to return or uninstall the product. Hyco Manufacturing Ltd Normandy Court Express Way...
