Specifications - Kewtech KT35 Instruction Manual

4

Specifications

Insulation Resistance Measurement Specification
Test Voltage
Measuring Ranges
Nominal Output
Voltage (UN)
Nominal Output
Current (In)
20MΩ
200Mz
Intrinsic
Accuracy
2000MΩ
Continuity Resistance Measurement Specification
Measuring Ranges
Open circuit voltage (Uq)
on the 20Ω range
Nominal output current (In)
on the 20Ω range
Intrinsic accuracy
Reference Conditions
Ambient Temperature: 23 ± 5°C
Relative Humidity:
Supply Voltage:
Altitude:
6
250V
0 -20M Ω
0 -200M Ω
0 -2000M Ω
250V DC min. 500V DC min. 1000V DC min.
at 0.25MΩ
1mA DC min.
at 0.25MΩ
0 to 1GΩ
±(10% rdg + 3 dgt)
1G to 2Gz
0 -20Ω
±(1.5% rdg+ 5dgt)
60 ± 15%
9 V
Less than 2000m
500V
0 -20M Ω
0 -200M Ω
0 -2000M Ω
at 0.5MΩ
1mA DC min. 1mA DC min.
at 0.5MΩ
±(5% rdg + 5 dgt)
0 -200Ω
4 - 9V
200 mA
0 -20Ω
1000V
0 -20MΩ
0 -200MΩ
0 -2000MΩ
at 1MΩ
at 1MΩ
±(3% rdg + 3 dgt)
0 - 2000Ω
0 -200Ω+0 - 2000Ω
±(1.5% rdg+ 3dgt)
