3.3.4 GENERAL PURPOSE OUTPUTS
Three general purpose inputs are available on the TRANSIT Entry reader. The
installed firmware may use these outputs for synchronous communication
interfaces such as Wiegand, Barcode and Magstripe. See chapter 3.2.3 for more
details.
Connections:
OUT1
General purpose output 1
OUT2
General purpose output 2
OUT3
General purpose output 3
GND
Ground
Figure 15: GPIO inputs
© Nedap IDEAS, P.O. Box 103, NL-7140 AC GROENLO
General purpose outputs
K2
TRANSIT Entry
Page 18 of 27
