3.2.4 USB CONNECTION

The TRANSIT Entry features an USB interface for service and installation purposes.
The USB connector (Type B) is accessible behind the service cover.
Figure 11: USB interface
Note: While the USB interface is in use, the on-board RS232 and RS422
interfaces are disabled. Also when an optional interface board is placed
(e.g. TCP/IP) the board will be disabled as long as the USB interface is in
use.
USB Driver installation
Make sure your computer is connected to the internet. The driver should install
automatically via Windows update when the TRANSIT Entry is connected to your
PC via the USB cable. Follow the driver installation wizard. If you do not see the
Windows update pop-up, you can manually install the driver. To manually install,
you need to go to FTDI's website at
download the VCP (Virtual Com Port) drivers for your operating system. Drivers for
MacOS and Linux are available as well.
© Nedap IDEAS, P.O. Box 103, NL-7140 AC GROENLO
USB type B
www.ftdichip.com/Drivers/VCP.htm
TRANSIT Entry
and
