3.3.3 GENERAL PURPOSE INPUTS
Three general purpose inputs are available on the TRANSIT Entry reader. The
inputs are active low.
Connections:
IN1
General purpose input 1
IN2
General purpose input 2
IN3
General purpose input 3
GND
Ground
Figure 14: GPIO inputs
