1. Scope of delivery and designations

Please check before installation, if all parts are present!
Important: There is only one LNB included, depending on which antenna you
purchased (single, twin or quad)
No. Part name
1
2 LNB clamping screw
3 LNB fixation screw
4 Angle bracket
5 Mounting Arm
6 Mounting plate A
7 Mounting plate B
8 Window holder A
9 Window holder B
04
Antenna
Figure Q'ty
1
2
1
1
1
1
1
1
1
