Chapter 1: Touring the Chassis

DIFF OUT: B

Figure 1-4

Mixed-Channel Vault L Storage Box

This version supports both single-ended and differential drives. The

Note:

mixed-channel Vault L also has a connector called SE TERM A. This

connector is not pressent on the differential Vault L.

AC receptacle

Voltage selector

SE TERM: A

SCSI B

(in)

SCSI A

(in)
